3
ENGLISH
For buttons not explained here, see the page indicated in parentheses ( ).
6
y
u
q
w
e
r
t
i
o
u i o
Q0
Q3
Q4
Q1
Q1Q0
Q2
q POWER switch ··············································(7)
w SPEED button ···············································(7)
e Insulator ························································(5)
r START/STOP button ····································(7)
t Lock nut ·························································(5)
y Tone arm ·······················································(5)
u Armrest ·························································(5)
i Lifter lever ·················································(6, 7)
o ANTI-SKATING knob ····································(6)
Q0 Stylus pressure adjustment ring ················(6)
Q1 Counterweight ··············································(6)
Q2 Dust cover ·····················································(5)
Q3 Arm height adjustment ring ························(5)
Q4 Arm height lock knob ··································(5)
Part names and functions
1.DP-A100E3_ENG_004_0825.indd 3 2010/08/26 8:59:07
