Set up the subwoofer
If using a subwoofer capable of the following
adjustments, set up the subwoofer as shown below.
For details, see your subwoofer’s manual.
n When using a subwoofer with a direct mode
Set the direct mode to “On” and disable the volume adjustment
and crossover frequency setting.
n When using a subwoofer without a direct mode
Make the following settings:
•Volume : “12 o’clock position”
•Crossover frequency : “Maximum/Highest Frequency”
•Low pass filter : “O”
•Standby mode : “O”
1
Prepare the included Setup and
measurement microphone
Mount the Setup and measurement microphone on
a tripod or stand and place it in the main listening
position.
When placing the Setup and measurement microphone, adjust
the height of the sound receptor to the level of the listener’s
ear.
Sound receptor
Setup and
measurement
microphone
If you do not have a tripod or stand, set up the microphone on, for
example, a seat without a back.
NOTE
•Do not hold the Setup and measurement microphone in your hand
during measurements.
•Avoid placing the Setup and measurement microphone close to a
seat back or wall as sound reflections may give inaccurate results.
Set up speakers (Audyssey® Setup)
3
Connect the Setup and measurement microphone to
the SETUP MIC jack of this unit.
When the Setup and
measurement microphone is
connected, the following screen is
displayed.
Audyssey Setup
Your AVR can automatically measure the
acoustics of your room and the optimize
your speakers.
Start
•For information about setting up and connecting the speakers,
see “Installation/connection/setup of speakers (Advanced)”
(vpage74).
•For connection to a TV, see “Connecting this unit to a TV via HDMI
connections” (vpage9).
Preparation
Basic instructions
Advanced instructions
Information
Basic instructions
v See overleaf
