English
DXZ366MP
• File extensions
• Always add a file extension “.MP3” or “.WMA”
to MP3 or WMA file by using single byte letters.
If you add a file extension other than specified
or forget to add the file extension, the file
cannot be played.
CD/MP3/WMA Mode Operations
• Logical format
(
File system
)
1. When writing MP3/WMA file on a CD-R disc or
CD-RW disc, please select “ISO9660 level 1, 2
or JOLIET or Romeo” as the writing software
format. Normal play may not be possible if the
disc is recorded on another format.
2. The folder name and file name can be
displayed as the title during MP3/WMA play
but the title must be within 64 single byte
alphabetical letters and numerals
(
including
an extension
)
.
3. Do not affix a name to a file inside a folder
having the same name.
• Folder structure
1. A disc with a folder having more than 8
hierarchical levels will be impossible.
• Number of files or folders
1. Up to 255 files can be recognized per folder.
Up to 512 files can be played.
2. Tracks are played in the order that they were
recorded onto a disc.
(
Tracks might not always
be played in the order displayed on the PC.
)
3. Some noise may occur depending on the type
of encoder software used while recording.
CD-DA/MP3/WMA selection on
multi-session CD
1. If a multi-session CD which contains CD-DA
and MP3/WMA files is being inserted, user can
select either CD-DA or MP3/WMA files to be
played.
2. Default setting for files to be played on
multisession CD is CD-DA files.
3. Press the
[
BND
]
button for more than 1 second
will toggle between selection of CD-DA and
[
MP3/WMA
]
files to be played.
4. When CD-DA type is selected, display will
show “M-SESS CD”. When MP3/WMA type is
selected, display will show “M-SESS MP3”.
7. When a mixed mode CD is loaded and CD is
set, the track to be played first is MP3/WMA
file data and no sound is heard.
Note:
• When playing a CCCD (Copy Control CD), set the
setting to CD type. When this is set to MP3/WMA
type, the CD cannot be played normally in some
cases.
Play MP3/WMA
Play CD
Play MP3/WMA
Setting
Disc
Mixed with CD
and MP3/WMA
type tracks
CD type track only
MP3/WMA type
track only
Play CD
Play CD
Play MP3/
WMA
Set to CD Set to MP3/WMA
Disc-In-Play function
As long as the ignition key is turned to the ON
or ACC position, this function allows you to turn
the power to the unit and start playing the disc
automatically when the disc is inserted even if the
power is not turned on.
• Do not try to put your hand or fingers in the
disc insertion slot. Also never insert foreign
objects into the slot.
• Do not insert discs where adhesive comes
out from cellophane tape or a rental CD label,
or discs with marks where cellophane tape
or rental CD labels were removed. It may be
impossible to extract these discs from the
unit and they may cause the unit to break
down.
CAUTION
!
Backup eject function
Just pressing the
[ ]
button ejects the disc even
if the power to the unit was not turned on.
1. Press the
[
OPEN
]
button to open the FLIP
DOWN PANEL.
5. CD-DA/MP3/WMA selection function can only
be performed in CD/MP3/WMA mode. It will
only activate after re-insert CD. For example,
current setting is CD-DA type. Press
[
BND
]
button for more than 1 second to set MP3/WMA
type. User has to eject CD and re-insert again
as to play MP3/WMA files.
6. Types of recording that can be played are as
follows.
