6 DPH910
Standard-mode functions <G.EQ (Graphic Equalizer) functions>
G.EQ effect ON/OFF switching
You can turn the sound quality effect of the G.EQ
ON or OFF by operating the buttons of the source
unit.
Selection of the basic G.EQ menus
6 basic G.EQ menus are stored in the DPH910.
You can select an appropriate sound quality ac-
cording to the music.
The basic G.EQ menus are as follows:
1. BASS BOOST;
Low frequencies emphasized.
2. HIGH BOOST;
Medium and high frequencies emphasized.
3. ACOUSTICAL;
Medium frequencies (vocals) emphasized.
4. IMPACT;
Low and high frequencies emphasized.
5. SMOOTH;
Medium and high frequencies reduced.
6. FLAT;
Original sound.
Editing the G.EQ
You can adjust the sound quality using the G.EQ
menus as you like.
The settings for the basic G.EQ menus are shown
in the following table. The adjustment range of
each frequency is between -12dB and +12dB.
G.EQ memory (User memory)
You can store 6 kinds of sound quality into the
memory which are edited on the basis of the basic
G.EQ menus.
DSF effect ON/OFF switching
You can turn the sound field effect of the DSF
ON or OFF by operating the buttons of the source
unit.
Setting of the listening position
You can select one of the preadjusted listening
positions according to the seat position.
The following 6 listening positions are available:
FULL SEAT, FRONT-RIGHT, FRONT-LEFT,
FRONT, REAR and PASS.
Fine-tuning the Listening Position
The time taken for the sound to leave the speaker
and reach you can be fine-tuned to create a natu-
ral sound field, no matter where you are sitting in
the car.
Selection of the sound field (DSF) menus
12 basic DSF menus are stored in the DPH910.
You can select an appropriate sound field accord-
ing to the music.
The basic DSF menus are as follows:
BASIC 1
1. HALL: Large concert hall.
2. CHURCH: Church with a vaulted ceiling.
3. STADIUM: Large stadium without roof or
walls.
4. LIVEHOUSE: Live performance hall, larger
than a jazz club.
5. CLUB: Club with strong bass.
6. JAZZCLUB: Jazz club with a low ceiling.
BASIC 2
1. DOME: Indoor sports arena.
2. CHAMBER: Large, echoing hall.
3. PARK: Vast outdoor area.
4. THEATER: Movie or drama theatre.
5. STUDIO: Listening room in a home.
6. BGM: Vocals cut.
Standard-mode functions <DSF functions>
Graphic equalizer parameter (dB)
Equalizer setting
50Hz
+5
0
0
+4
+2
0
100Hz
+6
0
+2
+4
+2
0
200Hz
-4
0
+1
+3
0
0
400Hz
+2
-2
+4
+1
-2
0
1kHz
0
+4
+6
+3
-4
0
3kHz
0
+3
+5
+5
-4
0
12kHz
0
+4
+1
+5
-2
0
1. BASS BOOST
2. HIGH BOOST
3. ACOUSTICAL
4. IMPACT
5. SMOOTH
6. FLAT
