14 DPH910
8. SPECIFICATIONS
● S/N ratio: ........................................... 107 dB (digital input)
83 dB (analogue input)
● Frequency response: ........................ 10 Hz to 20 kHz (±1 dB)
● Separation:........................................100 dB (digital input)
80 dB (analogue input)
● Harmonic distortion: ......................... 0.006% (digital input)(1 kHz)
0.006% (analogue input)(1 kHz)
● Voltage gain: .....................................2.5 dB (Volume max : 4V pre-out)
● Analogue input:................................. 1.5 VRMS (Max.)
● Digital input: ...................................... 44.1 kHz sampling frequency, 16-bit digital audio data
● A/D conversion: ................................ 20-bit linear, 64 times oversampling
● D/A conversion: ................................ 24-bit linear, 128 times oversampling
● DSF:
Basic: ................................................ 12 modes
User: ................................................. 6 modes
● Graphic equalizer (7 bands):
Basic: ................................................ 6 modes
User: ................................................. 6 modes
● Virtual Speace Enhancer:
Basic: ................................................ 6 modes
User: ................................................. 6 modes
● Parametric equalizer:........................ 3 bands x 2 (independent front/rear)
Center frequency: ............................. 20 Hz to 20 kHz, 1/3 octave steps, 31 points
Q curve: ............................................ 1 to 20
GAIN: ................................................ ±12 dB
Preset:............................................... 6 types
● Auto loudness: .................................. on/off
● Subwoofer:
Voltage gain: ..................................... +12 dB (max. woofer volume)
LPF cut off frequency: ...................... Through, 50 Hz, 80 Hz, 120 Hz
LPF slope:......................................... 24 dB/oct
● Front / Rear:
HPF cut off frequency:...................... Through, 50 Hz, 80 Hz, 120 Hz
HPF slope: ........................................ 18 dB/oct
● Power supply voltage:....................... DC 14.4V (10.8V to 15.6V), negative ground
● Power consumption: ......................... 560 mA
● External dimensions: ........................ 9-1/16˝ (W) x 1˝ (H) x 6-11/16˝ (D)
[230 (W) x 25 (H) x 170 (D)mm]
● Weight: .............................................. 2.091lb. (0.95 kg)
