3 DPH910 4 DPH910 DPH910 49
2. IDENTIFICATION OF PARTS
DPH910
1 CeNET input/output terminal
Connect the CeNET cable.
∗ Equipment to this terminal is not specified.
2 Front RCA terminals
Connect the RCA cable.
3 Rear RCA terminals
Connect the RCA cable.
4 Subwoofer RCA terminals
Connect the RCA cable.
5 Digital signal input terminal
Connect the digital optical fiber cable.
∗ After connection, be sure to fix it with the cable
clip.
6 Reset switch
When no sound is heard, press this switch.
Note:
Pressing the reset switch performs the system
check.
7 Cable clip insertion holes
Insert the cable clip in this hole and fix the
digital optical fiber cable.
Accessories
1 Name plate ............................... 1 sheet
2 RCA cable ................................ 2 pieces
3 CeNET cable ............................ 1 piece
4 Ground lead .............................. 1 piece
5 Mounting bracket ...................... 2 pieces
6 Cord clamp ............................... 2 pieces
7 Canoe clip ................................. 4 pieces
8 Mounting screw ........................ 4 pieces
9 Cable clip .................................. 1 pieces
3. FEATURES
■ Switchable Subwoofer Output (Stereo/Mono) and Adjustable Line Level Subwoofer Output
■ Selectable Subwoofer Low Pass Frequency and High Pass Frequency
■ 4V/6ch Gold-Plated RCA Line Level Output, 2 Optical Digital Inputs
< STD mode >
■ 12 Pre-Programed and 6 User Programmable Sound Field Memories
■ 7 Adjustable Sound Field Parameters
■ 5 Seating Position Memories
■ 7 Band Digital Graphic Equalizer
■ 6 Pre-Programed and 6 User Programmable Grapic Equalizer Memories
< Pro mode >
■ 6 Pre-Programed and 6 User Programmable Virtual Space Enhancer Memories
■ 3 Adjustable Virtual Space Enhancer Parameters
■ 3 Band Front and Rear Independent Digital Parametric Equalizer
■ 6 Front and 6 Rear Pre-Programed Parametric Equalizer Memories
2.
IDENTIFICATION OF PARTS / PRINCIPALES PIÈCES /
IDENTIFICACIÓN DE PARTES
DPH910
Accessories / Accessoires / Accesorios
