Clarion CZ109 CD Player User Manual



English
14 CZ109
Operations Common to
Each Mode
Setting the clock
2-1. Select “CLOCK”.
3-1. Press the [ ] button
3-2. Press [x] or [v] to select the hour or
minute.
3-3. Turn the [ROTARY] knob to set the time.
The clock is displayed in 12-hour format.
3-4. Press the [ ] button to store the time in
memory and return to the previous mode.
Note:
• You cannot set the clock when it is displayed
with only the car’s ignition on. If the car’s battery
dies or is removed, or the unit is removed, the
clock will be reset. If another button/operation is
selected while setting the clock, the clock set
mode is canceled.
Displaying the settings
You can see the state of current settings at any
operation mode.
2-1. Select “SETTINGS”.
3-1. Turn the [ROTARY] knob to display the
current settings.
When the setting is selected, the current
state will be displayed after 1 second.
Turning the screen saver on/off
This unit has a screen saver function in which
various patterns and random characters can be
displayed on the operation status indication
area. This function can be turned on/off. If a
button is pressed while the screen saver is on,
the corresponding operation display is shown
for about 30 seconds, and then the display
returns to the screen saver.
The factory default setting is “ON”.
2-1. Select “SCRN SVR”.
3-1. Turn the [ROTARY] knob to select “ON” or
OFF”.
Setting title scroll method
Set how to scroll in CD-TEXT and MP3/WMA
titles.
The factory default setting is “ON”.
2-1. Select “SCROLL”.
3-1. Turn the [ROTARY] knob to select “ON” or
OFF”.
ON: Scroll automatically.
OFF: Scroll 1 time only.
Setting dimmer control
Dimmer control can be set “ON” or “OFF”.
The factory default setting is “ON”.
2-1. Select “DIMMER”.
3-1. Turn the [ROTARY] knob to select “ON” or
OFF”.
Setting car speaker output for cell
phones
When the AUX input jack is used to connect an
AUX BLUETOOTH BB (BLT370) (sold
separately):
The factory default setting is “RIGHT”.
To output the telephone calls, set cell phone
interrupt to “ON”.
2-1. Select “TEL-SP”.
3-1. Turn the [ROTARY] knob to select “RIGHT
or “LEFT”.
RIGHT: Telephone calls can be heard on
the front right speaker connected to this
unit.
LEFT: Telephone calls can be heard on
the front left speaker connected to this
unit.
To change settings
1. Press and hold the [DISP] button (1 sec.)
to switch to the adjustment display.
2. Press [x] or [v] to select the “item
name” as follows:
CLOCKSETTINGSSCRN SVR
SCROLLDIMMERTEL-SP
TEL-SW
The adjustment item will be displayed for 2
seconds before showing the desired value.
3. Turn the [ROTARY] knob to select the
desired value.
When “ENT” is flashing in the display, press
the [ ] button to adjust setting value.
4. After completing settings, press the [DISP]
button to return to the previous mode.
Example: After 1 second:
