English
10 CZ109
● Adjusting the balance
2-1. Select “BALANCE”.
3-1. Turn the [ROTARY] knob to adjust balance
between right and left speakers.
∗ The factory default setting is “CENTER”.
(Adjustment range: RIGHT12 to LEFT12)
● Adjusting the fader
2-1. Select “FADER”.
3-1. Turn the [ROTARY] knob to adjust balance
between front and rear speakers.
∗ The factory default setting is “CENTER”.
(Adjustment range: FRONT12 to REAR12)
● Adjusting the non-fader volume
Adjust volume output from the unit’s non-fader
output terminal.
2-1. Select “NF VOL”.
3-1. Turn the [ROTARY] knob clockwise to
increase volume; turn counterclockwise to
decrease volume.
∗ The factory default setting is “0”.
(Adjustment range: +6 to –6)
Note:
• When in the sound adjustment mode, if no
operation is performed for 10 seconds or more,
the mode is cancelled and the unit returns to the
previous mode.
Setting the MAGNA BASS EXTEND
The MAGNA BASS EXTEND function does not
adjust low frequencies like normal sound
adjustments, but emphasizes the deep bass
range with dynamic sound.
∗ The factory default setting is “OFF”.
1. Press and hold the [SOUND] button (1 sec.)
to enable MAGNA BASS EXTEND.
2. Press and hold the [SOUND] button (1 sec.)
to disable MAGNA BASS EXTEND.
Radio Operations
Listening to broadcasts
1. Press the [SRC] button and select radio
mode.
2. Press the [BND] button and select the
reception band. Each time the button is
pressed, the band changes as follows:
F1 (FM1) ➜ F2 (FM2) ➜ F3 (FM3) ➜ AM ➜
F1 (FM1)...
Tuning
3 tuning modes are available: seek tuning,
manual tuning and preset tuning.
Seek tuning
1. Press the [BND] button and select the
desired band (FM/AM).
∗ If “MANU” appears in the display, press and
hold the [BND] button (1 sec.). “MANU” will
turn off, and seek tuning will be enabled.
2. Press [x] or [v] to automatically seek a
station.
Manual tuning
2 modes are available: Quick tuning and step
tuning.
● Quick tuning
Press and hold [x] or [v] (1 sec.) to tune a
station.
● Step tuning
Press [x] or [v] to manually tune a station.
Recalling a preset station
A total of 24 preset positions (6-FM1, 6-FM2, 6-
FM3, 6-AM) can be used to store broadcast
stations in memory. Press the corresponding
[DIRECT] button to automatically recall the
stored frequency.
