11 CZ109
Manual memory
1. Use seek tuning or manual tuning to select
the desired station.
2. Press and hold one of the [DIRECT] buttons
(2 sec.) to store the current station in preset
memory.
Auto store
The auto store function stores up to 6 stations
automatically tuned in sequential order. If 6
stations cannot be found, any previously stored
station remains in its memory position.
1. Press the [BND] button and select the
desired band (FM/AM).
2. Press and hold the [ ] button (2 sec.). The
stations with good reception are stored
automatically to the preset channels.
∗ If auto store is performed in the FM bands, the
stations are stored in FM3 even if FM1 or FM2
was chosen for storing stations.
Preset scan
Preset scan sequentially receives stations
stored in preset memory. This function is useful
when searching for a station stored in the
memory.
1. Press the [ ] button.
2. When the desired station is received, press
the [ ] button again to continue receiving
that station.
Note:
• Do not press and hold the [ ] button (2 sec.),
or the auto store function will begin and the unit
will begin storing stations.
Instant station recall (ISR)
The ISR function allows instant access to a
favorite preset station. The function operates
even when the unit is in other modes.
● ISR memory
1. Select the station you wish to store in ISR
memory.
2. Press and hold the [ISR] button (2 sec.).
● Recalling a station with ISR
While in any mode, press the [ISR] button to
turn on the radio function and tune the selected
station. “ISR” appears on the display. Press the
[ISR] button again to return to the previous
mode.
CD/MP3/WMA Operations
MP3/WMA
This unit supports to play MP3/WMA files.
Notes:
• If you play a WMA file with active DRM (Digital
Rights Management), no audio is output (WMA
indicator flashes).
• Windows Media™, and the Windows ® logo are
trademarks, or registered trademarks of
Microsoft Corporation in the United States and/or
other countries.
● To disable DRM (Digital Rights
Management)
1. In Windows Media Player 9/10/11, click on
TOOL ➜ OPTIONS ➜ MUSIC RECORD tab.
Under Recording settings, unclick the check
box for RECORD PROTECTED MUSIC.
Then reconstruct files.
Use personally constructed WMA files at
your own responsibility.
Precautions when creating MP3/
WMA files
● Usable sampling rates and bit rates
1. MP3: Sampling rate: 8 kHz-48 kHz,
Bit rate: 8 kbps-320 kbps / VBR
2. WMA: Bit rate: 48 kbps-192 kbps
● File extensions
1. Always add a file extension “.MP3” or
“.WMA” to MP3 or WMA files using single
byte characters. If a different or no file
extension is appended, the file cannot be
played.
2. Files without MP3/WMA data will not play.
Instead, “– –:– –” will appear in the play time
display.
● Logical format (File system)
1. When writing MP3/WMA files on a CD-R or
CD-RW disc, select “ISO9660 level 1, 2, or
JOLIET or Romeo” as the software format.
Normal playback may not be possible if
recorded in other formats.
2. The folder name and file name can be
displayed as the title during MP3/WMA play.
However titles must be within 64 single byte
alphabetical letters and numbers (including
extension).
3. Do not affix a name to a file inside a folder
with the same name.
