12 CZ109
● Number of files or folders
1. Up to 256 files can be recognized per folder.
Up to 578 files can be played.
2. Tracks are played in the order they were
recorded onto the disc. (Tracks may not
always be played in the order displayed on
the PC.)
3. Some noise may occur depending on the
type of encoder software used for recording.
Disc-In-Play function
This function automatically turns on unit power
and begins disc play if a disc is inserted when
the car’s ignition key is turned to the ON or ACC
position.
CAUTION
• Do not insert hands, fingers, or other
foreign objects into the disc insertion slot.
• Do not insert discs with adhesives such as
cellophane tape or rental CD labels
attached, or discs with marks left from
removal of such adhesives, since the disc
may become stuck and damage the unit.
Ejecting a CD
1. Press the [Q] button to eject the CD. Take it
out from the ejected position. “EJECT”
appears in the display.
Notes:
• If you force a CD in before auto reloading, you
may damage the CD.
• If a CD (12 cm) is left ejected for 15 seconds, it
will be automatically reloaded (auto reload).
Listening to a disc already loaded in
the unit
Press the [SRC] button to select CD/MP3/WMA
mode.
When the unit enters this mode, playback starts
automatically.
If no disc is loaded, “NO DISC” appears in the
title display.
Loading a CD
1. Insert a CD into the centre of the CD SLOT
with label facing up. “LOADING” appears in
the display, the CD enters the slot, and play
begins.
Notes:
• If the CD does not enter easily, another CD may
be in the unit, or the unit may require service.
• Discs without the or mark and CD-
ROMs are not supported.
• Some CD-R/CD-RW discs may not be usable.
Pausing play
1. Press the [ ] button to pause play.
“PAUSE” appears in the display.
2. To resume CD play, press the [ ] button
again.
Displaying CD titles
This unit can display title data for CD-text/MP3/
WMA discs.
1. Each time the [DISP] button is pressed, the
title display will change.
● CD-TEXT discs
Track ➜ Disc ➜ Artist ➜ Track ...
● MP3/WMA discs
Track ➜ Folder ➜ Title ➜ Album ➜ Artist ➜
Track ...
Notes:
• If the CD playing is not a CD-text disc or no user
title has been input, “NO TITLE” appears in the
display.
• If an MP3/WMA disc has no Tag input, “NO
TITLE” appears in the display.
• This unit supports MP3 ID3 Tags V2.3 / 2.2 / 1.1 /
1.0.
• Tag display gives priority to V2.3 / 2.2.
• For WMA album Tags, the information written into
the extension header is displayed.
• ISO8859-1, ASCII, S-JIS characters can be
displayed in Tags.
UNKNOW characters can be turned into
ISO8859-1 characters.
• Titles up to 32 bytes can be displayed in CD/
MP3/WMA mode.
