AXIS P7210 Video Encoder
Technical Specications
Function/group
Item
Specications
Application
Programming
Interface
Open API for software integration, including VAPIX® from Axis Communications available
at www.axis.com
Includes the ONVIF Prole S; specication at www.onvif.org Support for AXIS Video
Hosting System (AVHS) with One-Click Camera connection
Intelligent video Video motion detection, active tampering alarm
Event triggers Intelligent video, Audio detection, external inputs, edge storage events
System
Integration
Event actions File upload via FTP, HTTP, network share and email
Notication via email, HTTP and TCP
PTZ preset
External output activation
Play audio clip
Pre- and post-alarm video buffering
Casing Standalone, rackmount or wallmount
Processor,
memory
4x ARTPEC-4, 4 x 512 MB RAM, 4x 128 MB Flash
Power
8-20 V DC, max 32W; 4 x Power over Ethernet IEEE 802.3af Class 3, AXIS PS-P power
supply
Use the supplied mains adaptor or a limited power source, which rated power output
does not exceed either 100 W or 5 A
Connectors
16x analog composite video inputs (BNC)
8x mono microphone or line inputs, 6Vpp max (3.5 mm jacks)
4x mono audio output, 2Vpp max at 1kohm (3.5 mm jack)
4x 10BASE-T/100BASE-TX Ethernet
16x Congurable external inputs/outputs (terminal blocks)
4x RS-485/422 full duplex (terminal blocks)
1x DC input terminal block
Local storage
4x microSD/SDHC
Operating
conditions
0 – 50 °C (32 – 122 °F)
Humidity 20 – 80% RH (non-condensing)
Approvals
EN 55022 Class B
EN 61000-3-2
EN 61000-3-3
EN 55024
EN 61000-6-1
EN 61000-6-2
FCC Part 15 Subpart B Class B
ICES-003 Class B
VCCI Class B
C-tick AS/NZS CISPR 22 Class B
KCC KN22 Class B, KN24
IEC/EN/UL 60950-1
Weight
2540 g
General
Included
accessories
Power supply, mounting and connector kits, Installation Guide, CD with installation and
management tools, software and User’s Manual, Windows decoder user licenses
Dimensions
(HxWxD)
45 x 440 x 165 mm
