Thank you for purchasing the Altec Lansing PT8051 Wireless Surround
Sound System.
The PT8051 is designed to replace the traditional A/V receiver and
separate speakers and provide a complete, multi-channel surround
system sound from just two components using DTS and Dolby Digital
decoding to faithfully reproduce your favorite music and movie
soundtracks.The PT8051 system’s NXT Digital flat-panel driver
technology accurately reproduces the full frequency range and delivers
all the subtleties and spatial depth that today’s digital formats are
capable of. In addition, the PT8051’s advanced wireless transmission
means it’s easy to experience theater quality surround effects without
the need to run wires to the rear speakers.
T
he PT8051’s design is well suited for use with today’s large format
LCD and plasma flat panel displays and both components can be wall
mounted with them using the supplied brackets. A universal remote
control is included that allows you to consolidate remote controls from
various devices such as your TV, DVD player and VCR.
Contents
Refer to the PT8051 Quick Connect Card to identify these items.
• PT8051 main and rear surround units
• Remote control and batteries
• A/V Cable
• Wall mount bracket (hardware not included)
• User’s guide and quick connect instructions
Controls and Connections for Your PT8051
Front Panel (Main Unit)
Rear Panel (Main Unit)
PT8051 Surround Sound System
1
2
3
4
5
1.VOLUME +/– Controls the volume level of all audio channels.
2. LEDs Displays information about the operational status.
3. INPUT
Press to switc
h between input sour
ces (D
VD,
TV/SAT,
A
UX, D
VD dig
ital, TV/SAT digital or AUX digital).
4. MODE Press to select the surround (DOLBY, DTS or PRO
LO
GIC II) or ster
eo (S
TEREO) mode.
5.
P
O
WER
Pr
ess to power on the system or switch to standb
y.
1. Power ON/OFF Switches power on or off.
2. AC Power Cord Connect to standard AC outlet. Refer to
frequency and voltage range for Power Source
as indicated on rear panel.
3. CONNECT Press this button to manually synchronize the
wireless audio link between the main and rear
surround units. Under most circumstances it is
not necessary to use this button as the units
automatically synchronize when powered on.
4.VIDEO OUT Used to display on-screen display information.
Connect to composite video input of TV.
5. SUBWOOFER OUT
Use to connect an optional subwoofer if
additional bass is required from the system.
6. DIGITAL INPUT:
COAXIAL (DVD IN)
Use to connect a DVD player that has a
coaxial digital output.
OPTICAL
(TV/SAT IN)
Use to connect a digital satellite tuner or cable
TV tuner that has an optical audio output.
OPTICAL (AUX IN)
Use to connect to an auxiliary sound source
such as a PVR or second TV tuner that has an
optical audio output. Can also be used to
connect a DVD player that has an optical
output but not a coaxial output.
7. AUDIO ANALOG
INPUT: DVD IN
Use to connect to a DVD player with audio
analog output.
TV/SA
T IN
Use to connect to a
TV or satellite tuner with
audio analo
g output.
1
2
3
4
5
6
7
PT8051
4
