MERLIN 232
7.1 System Performance
Modulation: FM
Carrier frequency band: 864 MHz (LPD band) or 916 MHz
Selectable carrier frequencies: FREQ 1: 863.5 MHz/915.5 MHz
FREQ 2: 864.0 MHz/916.0 MHz
FREQ 3: 864.5 MHz/916.5 MHz
72 MERLIN T 232 Transmitter
Power supply: 1.5 VDC, ≥650 mA (1 x 1.2 V, 650 mAh AAA size NiMH rechargeable battery supplied)
Radiation angle: approx. 360°
Max. radiated power: 10 mW ERP (Equivalent Radiated Power)
Battery life: approx. 5 hours (NiMH rechargeable battery)
Max. range (free field*): 864 MHz: approx. 262 ft. (80 m)
916 MHz: approx. 82 ft. (25 m)
Weight: approx. 1.3 oz. (37 g)
7.3 MERLIN K 232 Headphones
Distortion: <1%
Type: semi-open dynamic headphones
Power supply: 3 VDC (2 x 1.2 V, 600 mAh AAA size NiMH rechargeable batteries supplied)
Battery life: approx. 20 hours (NiMH rechargeable batteries)
Audio bandwidth: 20 Hz to 22,000 Hz
Max. SPL: ~103 dB SPL
Weight: approx. 6 oz. (172 g)
* under ideal transmission conditions
This equipment (864 MHz version) conforms to the standards listed in the Declaration of Conformity.
7 Specifications
