8 Pelco Manual C1402M-B (2/98)
3.0 INSTALLATION
Save the shipping box and any inserts in case the unit must be returned for credit or
repair.
3.1 CONDUCTOR AND CABLE REQUIREMENTS
(ALL MODELS EXCEPT SB26)
A minimum of 12 conductors plus coax is required, which includes common re-
quirements for motorized zoom lens and camera AC power.
Non-PP Models
12 Conductor 13 Conductor*
20 Awg 130 ft (39.62 m) 185 ft (56.38 m)
18 Awg 205 ft (62.48 m) 290 ft (88.39 m)
16 Awg 326 ft (99.36 m) 461 ft (140.51 m)
Models with PP
18 Conductor 19 Conductor*
20 Awg 130 ft (39.62 m) 185 ft (56.38 m)
18 Awg 205 ft (62.48 m) 290 ft (88.39 m)
16 Awg 326 ft (99.36 m) 461 ft (140.51 m)
*Using 2-conductor common.
Calculations are based on a 10% cable loss with both motors running.
3.2 WIRING INSTRUCTIONS
The SB2600 and SB2600-SL include a pan/tilt which is pre-wired for all control
functions (pan/tilt, motorized zoom lens, camera power [24 VAC], and video). All
connections are made to the input connector, eliminating the need for wiring har-
nesses made in the field. Wire the control cable according to the wiring diagram in
Figures 1 and 2 (non-PP models), or Figures 3 and 4 (PP models).
NOTE:
The following are cable
requirements. A relay box (RB24) is
available to extend the operating dis-
tance up to 13,000 feet (3962.4 m)
over 16 Awg wire.
