Q1860-90918 8 Parts and diagrams 297
RS5-2439-000CN Spring, separation pad Figure 173 on page 277
RS5-2441-000CN Spring, compression Figure 164 on page 266
RS5-2632-000CN Spring, tension Figure 182 on page 286
RS6-0357-000CN Gear, delivery roller Figure 168 on page 272
RS6-0357-000CN Gear, lower delivery shaft Figure 164 on page 266
WG8-5362-000CN Sensor, PS402 Figure 164 on page 266
WG8-5362-000CN Sensor, PS403 Figure 164 on page 266
WG8-5375-000CN Sensor, face-down bin-full, PS307 Figure 164 on page 266
WS6-5092-000CN Power connector Figure 164 on page 266
XA9-0267-000CN Screw, M3x6, TP Figure 164 on page 266
XA9-0267-000CN Screw, TP, M3x6 Figure 174 on page 278
XA9-0815-000CN Screw, tp, M3x4 Figure 175 on page 279
XA9-0838-000CN Screw, M4x16, with washer Figure 167 on page 271
XB4-7301-207CN M3x12 screw, tapping, truss head Figure 182 on page 286
XB4-7401-007CN Screw, M4x10, tapping Figure 164 on page 266
XD2-1100-322CN E-ring Figure 166 on page 270
XD2-1100-322CN E-ring Figure 164 on page 266
Table 89. Numerical parts list (continued)
Part number Description Figure and page
