EPSON Stylus Color 900 Revision c
Appendix EEPROM ADDRESS MAP 178
Table 7-17. EEPROM Address Map (5/8) Table 7-18. EEPROM Address Map (6/8)
Address Explanation Settings
QPIT
settings
Factory
settings
34H Software
A.G.M.
Auto CR
Zero Slash
-
-
Network I/F mode
Auto LF
bit7: Software
(0=ESC/P, 1=IBM)
bit6: A.G.M. (0=Off, 1=On)
bit5: Auto CR (0=Off, 1=On)
bit4: Zero slash
(0=Off, 1=On)
bit3: Reserved
bit2: Reserved
bit1: Network I/F mode
(0=Off, 1=On)
bit0: Auto line feed
(0=Off, 1=On)
00H 00H
35H Panel mask
function
bit7: Entry Self-Test
bit6: Entry Hex-Dump
bit5: Extended settings
bit4: Reserved
bit3: Reserved
bit2: Cleaning
bit1: Replace l/C
bit0: Load/Elect
00H 00H
36H Top margin 42 to 44 x 360
(by1/360 inch)
00H 00H
37H 78H 78H
38H Bottom margin 1244 to 44 x 360
(by 1/360 inch)
1EH 1EH
39H F0H F0H
3AH Page length 1244 to 44 x 360
(by 1/360 inch)
1EH 1EH
3BH F0H F0H
3CH reserved for main 00H
−
3DH reserved for main 00H
−
3EH reserved for main 00H
−
3FH reserved for main 00H
−
Address Explanation Settings
QPIT
settings
Factory
settings
40H Password 1 0FH
−
41H 5AH
−
42H Ink flag 1 bit7: Reserved
bit6: black one-time
bit5: color one-time
bit4: Initial fill required
bit3: Reserved
bit2: ink cleaning seq.
bit1: black CL required
bit0: color CL required
00H 10H
43H Ink flag2 bit2: YMC cartridge changed
and cleaned
bit1: Black cartridge
changed and cleaned
bit0: Black cartridge
changed and cleaned
00H 00H
44H, 45H,
46H, 47H
Ink counter Cb 00H 00H
48H, 49H,
4AH, 4BH
Ink counter Cy 00H 00H
4CH, 4DH,
4EH, 4FH
Ink counter Cm 00H 00H
50H, 51H,
52H, 53H
Ink counter Cc 00H 00H
54H, 55H,
56H, 57H
Ink counter Clm 00H 00H
58H, 59H,
5AH, 5BH
Ink counter Clc 00H 00H
5CH, 5DH Ink counter Rb0 00H 00H
