SPECIFICATIONS
Frequency: 2332.5 to 2345.0 MHz
Bandwidth: 12.5 MHz
VSWR: 2:1
Terrestrial Reception: Linear polarization
Satellite Reception: Circular polarization
Input Impedance: 50 ohms
Coverage from Tuner: Terrestrial antenna is omnidirectional
Current Draw: 110 mA typical per antenna LNA
Input Voltage: 4.5 Vdc typical
LNA Noise Figure: 0.8 dB max.
Terrestrial Noise Figure: 1.3 dB max.
Total Active LNA Gain –
Terrestrial Reception: 18-22 dB
Satellite Reception: 20-24 dB
Out of Band Filter Attenuation: 25 dB min.
Cables: 11 feet coaxial
Connectors: FAKRA-type SMB (color coded)
Mounting Material: Adhesive pads (3M 5356 acrylic foam)
Materials: Radome impact-resistant glass-filled
nylon (paintable)
Radiated Immunity: 100 volts per meter,200 MHz to 2 Ghz
Weight: 6 oz (without cables)
Dimensions –
Antenna Module: 4-1⁄4" x 3-3⁄16" x 1-1⁄2"
Cable Cover (L x W x H): 6-3⁄4" x 5⁄8" x 7⁄32"
Temperature: -40 °C to +105 °C,operating
-45 °C to +120 °C,storage
Quality and Performance Tests –
XM Approved: Per specification XM-TEC-3-0009-RD
AES Approved: Tested and proven to AES
Terk QA: Shock and Vibration Proof
Terk Technologies strives to maintain and exceed the highest consumer standards.Due to these ongoing
efforts,modifications may be made from time to time to existing products without any prior notice.
Specifications and appearance may differ from those listed or shown in this manual.The XM name and
related logos are trademarks of XM Satellite Radio,Inc.Terk and Terk Technologies are trademarks of
Terk Technologies Corp.,Commack,NY.
Part # 49P005
Specifications 11
