TP-Link DA-500F-HL CU Stereo Amplifier User Manual



133-22-102-60
URL: http://www.toa.jp/
* 0 dB = 0.775 V
Note: The design and specifications are subject to change without notice for improvement.
Removable terminal plug (3 pins) ........................................ 4
Tamper-proof cap ................................................................ 4
• Accessories
120 V AC, 50/60 Hz
Digital class D
480 W (based on UL/CSA standards), 2600 W (rated output 8 Ω x 4)
4 circuits, +4 dB* (1.23 V, input level control in maximum position),
10 kΩ, electronically-balanced, Removable terminal block (3 pins),
XLR-3-31 type connector
CH 1 mode ON/OFF switch (ON: CH 1 to All ch, OFF: Each ch)
HPF ON/OFF switch (–6 dB/oct, cut off frequency 50 Hz)
4 channels: 500 W x 4 (9.8 Ω, 70 V line), 550 Wx 4 (8 Ω), 100 W x 4 (4 Ω)
2 channels (BRIDGE): 1,000 W x 2 (19.6 Ω), 1,100 W 2 (16 Ω)
M4 screw terminal, distance between barriers: 8.8 mm (0.35")
20 – 20,000 Hz (–2 dB, +1 dB): HPF OFF
50 – 20,000 Hz (–3 dB, +1 dB): HPF ON
0.1% (1 kHz)
0.3% (20 – 20,000 Hz): HPF OFF
0.3% (100 – 20,000 Hz): HPF ON
Protection against excessive current flow due to overload, short circuit,
unusual DC voltage output, and heat sink temperature rise (over 100°C)
100 dB (A-weighted)
70 dB (A-weighted)
Control input: Power ON/OFF status of the individual channels
Photocoupler input
drive voltage: 9 V DC (Min) – 14 V (Max), 12 V (Typ)
Monitor output: Power ON/OFF status of the individual channels, Protection
status of the individual channels, Fan operation status
Photocoupler open collector output
withstand voltage: 30 V DC,
control current: under 12 mA
Connector: RJ45 connector x 2
Connection cable: Category 5 twisted pair cable for LAN (CAT5-UTP)
Maximum cable distance: 600 m (656.17 yd)
Power (blue) x 1, Input (green) x 4, Output (yellow) x 4, Peak (red) x 4,
Protect (red) x 4
Forced air cooling
–10°C to +40°C (14°F to 104°F)
Under 90% RH (no condensation)
Panel: Aluminum, black, alumite
Case: Plated steel sheet
482. (w) x 88.4 (h) x 404.2 (d) mm (18.98" x 3.48" x 15.91")
8.8 kg (19.4 lb)
Power Source
Amplification system
Power Consumption
Input
Rated Output
Frequency Response
Total Harmonic Distortion
Protection circuit
S/N Ratio
Crosstalk
Control/Monitor
LED Indicator
Cooling
Operating Temperature
Operating Humidity
Finish
Dimensions
Weight
17.2. DA-500F-HL CU
