Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
25
STR-DE375
C364 1-126-961-11 ELECT 2.2uF 20.00% 50V
C365 1-126-961-11 ELECT 2.2uF 20.00% 50V
C366 1-126-961-11 ELECT 2.2uF 20.00% 50V
C367 1-136-165-00 FILM 0.1uF 5.00% 50V
C368 1-164-159-11 CERAMIC 0.1uF 50V
C371 1-164-159-11 CERAMIC 0.1uF 50V
C372 1-164-159-11 CERAMIC 0.1uF 50V
C373 1-164-159-11 CERAMIC 0.1uF 50V
C374 1-164-159-11 CERAMIC 0.1uF 50V
C375 1-164-159-11 CERAMIC 0.1uF 50V
C376 1-164-159-11 CERAMIC 0.1uF 50V
C401 1-126-795-11 ELECT 10uF 20.00% 50V
C402 1-126-795-11 ELECT 10uF 20.00% 50V
C403 1-126-795-11 ELECT 10uF 20.00% 50V
C404 1-126-795-11 ELECT 10uF 20.00% 50V
C405 1-126-795-11 ELECT 10uF 20.00% 50V
C412 1-130-481-00 MYLAR 0.0068uF 5% 50V
C414 1-130-481-00 MYLAR 0.0068uF 5% 50V
C416 1-136-169-11 FILM 0.22uF 5% 50V
C417 1-136-169-11 FILM 0.22uF 5% 50V
C418 1-137-375-11 MYLAR 0.068uF 5.00% 50V
C419 1-126-794-11 ELECT 4.7uF 20.00% 50V
C420 1-126-795-11 ELECT 10uF 20.00% 50V
C421 1-126-795-11 ELECT 10uF 20.00% 50V
C433 1-128-809-11 CERAMIC 100PF 5% 50V
C434 1-128-813-11 CERAMIC 220PF 5% 50V
C435 1-128-813-11 CERAMIC 220PF 5% 50V
C441 1-164-159-11 CERAMIC 0.1uF 50V
C442 1-164-159-11 CERAMIC 0.1uF 50V
C443 1-164-159-11 CERAMIC 0.1uF 50V
C445 1-164-159-11 CERAMIC 0.1uF 50V
C446 1-164-159-11 CERAMIC 0.1uF 50V
C447 1-164-159-11 CERAMIC 0.1uF 50V
C451 1-126-795-11 ELECT 10uF 20.00% 50V
C452 1-126-795-11 ELECT 10uF 20.00% 50V
C453 1-126-795-11 ELECT 10uF 20.00% 50V
C454 1-126-795-11 ELECT 10uF 20.00% 50V
C455 1-126-795-11 ELECT 10uF 20.00% 50V
C461 1-126-794-11 ELECT 4.7uF 20.00% 50V
C462 1-130-481-00 MYLAR 0.0068uF 5% 50V
C463 1-137-375-11 MYLAR 0.068uF 5.00% 50V
C464 1-130-481-00 MYLAR 0.0068uF 5% 50V
C465 1-126-795-11 ELECT 10uF 20.00% 50V
C466 1-126-794-11 ELECT 4.7uF 20.00% 50V
C467 1-136-169-11 FILM 0.22uF 5% 50V
C468 1-136-169-11 FILM 0.22uF 5% 50V
C470 1-126-795-11 ELECT 10uF 20.00% 50V
C472 1-126-794-11 ELECT 4.7uF 20.00% 50V
C480 1-126-965-11 ELECT 22uF 20.00% 50V
C481 1-126-965-11 ELECT 22uF 20.00% 50V
C482 1-126-965-11 ELECT 22uF 20.00% 50V
C483 1-126-965-11 ELECT 22uF 20.00% 50V
C501 1-126-794-11 ELECT 4.7uF 20.00% 50V
C502 1-128-809-11 CERAMIC 100PF 5% 50V
C503 1-102-989-00 CERAMIC 68PF 5.00% 500V
C504 1-102-989-00 CERAMIC 68PF 5.00% 500V
C505 1-104-665-11 ELECT 100uF 20.00% 10V
C506 1-102-936-00 CERAMIC 3.0PF +-0.25PF 50V
C510 1-104-664-11 ELECT 47uF 20.00% 25V
C511 1-137-372-11 MYLAR 0.022uF 5.00% 50V
C520 1-128-813-11 CERAMIC 220PF 5% 50V
C524 1-126-795-11 ELECT 10uF 20.00% 50V
C526 1-127-876-31 CERAMIC 0.01uF 10% 50V
C601 1-126-794-11 ELECT 4.7uF 20.00% 50V
C603 1-104-665-11 ELECT 100uF 20.00% 10V
C604 1-102-936-00 CERAMIC 3.0PF +-0.25PF 50V
C605 1-102-233-00 CERAMIC 33PF 10.00% 500V
C606 1-128-815-11 CERAMIC 330PF 5% 50V
C607 1-128-809-11 CERAMIC 100PF 5% 50V
C610 1-104-664-11 ELECT 47uF 20.00% 25V
C611 1-137-372-11 MYLAR 0.022uF 5.00% 50V
C614 1-127-876-31 CERAMIC 0.01uF 10% 50V
(CND,E,SP,MY,AR)
C620 1-128-813-11 CERAMIC 220PF 5% 50V
C624 1-126-795-11 ELECT 10uF 20.00% 50V
C626 1-127-876-31 CERAMIC 0.01uF 10% 50V
C651 1-126-794-11 ELECT 4.7uF 20.00% 50V
C653 1-104-665-11 ELECT 100uF 20.00% 10V
C655 1-102-233-00 CERAMIC 33PF 10.00% 500V
C657 1-128-809-11 CERAMIC 100PF 5% 50V
C660 1-104-664-11 ELECT 47uF 20.00% 25V
C661 1-137-372-11 MYLAR 0.022uF 5.00% 50V
C670 1-128-813-11 CERAMIC 220PF 5% 50V
C701 1-126-794-11 ELECT 4.7uF 20.00% 50V
C703 1-104-665-11 ELECT 100uF 20.00% 10V
C704 1-102-936-00 CERAMIC 3.0PF +-0.25PF 50V
C705 1-102-233-00 CERAMIC 33PF 10.00% 500V
C706 1-128-815-11 CERAMIC 330PF 5% 50V
C707 1-128-809-11 CERAMIC 100PF 5% 50V
C710 1-104-664-11 ELECT 47uF 20.00% 25V
C711 1-137-372-11 MYLAR 0.022uF 5.00% 50V
C714 1-127-876-31 CERAMIC 0.01uF 10% 50V
C720 1-128-813-11 CERAMIC 220PF 5% 50V
C721 1-126-934-11 ELECT 220uF 20.00% 10V
C722 1-126-795-11 ELECT 10uF 20.00% 50V
C724 1-126-795-11 ELECT 10uF 20.00% 50V
C726 1-127-876-31 CERAMIC 0.01uF 10% 50V
C734 1-126-795-11 ELECT 10uF 20.00% 50V
C736 1-127-876-31 CERAMIC 0.01uF 10% 50V
C740 1-128-582-11 ELECT 10uF 20.00% 100V
(CND,E,SP,MY,AR)
C740 1-126-795-11 ELECT 10uF 20.00% 50V
(AEP,UK)
C741 1-128-582-11 ELECT 10uF 20.00% 100V
(CND,E,SP,MY,AR)
C741 1-126-795-11 ELECT 10uF 20.00% 50V
(AEP,UK)
C742 1-126-935-11 ELECT 470uF 20.00% 10V
C743 1-126-935-11 ELECT 470uF 20.00% 10V
C751 1-126-794-11 ELECT 4.7uF 20.00% 50V
C753 1-104-665-11 ELECT 100uF 20.00% 10V
C755 1-102-233-00 CERAMIC 33PF 10.00% 500V
C757 1-128-809-11 CERAMIC 100PF 5% 50V
C760 1-104-664-11 ELECT 47uF 20.00% 25V
C761 1-137-372-11 MYLAR 0.022uF 5.00% 50V
C764 1-127-876-31 CERAMIC 0.01uF 10% 50V
(AEP,UK)
C770 1-128-813-11 CERAMIC 220PF 5% 50V
C801 1-126-965-11 ELECT 22uF 20.00% 50V
C802 1-126-965-11 ELECT 22uF 20.00% 50V
C803 1-165-498-11 ELECT 4700uF 20% 63V
MAIN
