Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
23
STR-DE375
R219 1-249-429-11 CARBON 10K 5% 1/4W
R220 1-249-407-11 CARBON 150 5% 1/4W F
R221 1-249-407-11 CARBON 150 5% 1/4W F
R222 1-249-407-11 CARBON 150 5% 1/4W F
R224 1-249-429-11 CARBON 10K 5% 1/4W
(CND,E,SP,MY,AR)
R225 1-249-429-11 CARBON 10K 5% 1/4W
(CND,E,SP,MY,AR)
R226 1-249-429-11 CARBON 10K 5% 1/4W
(CND,E,SP,MY,AR)
R227 1-249-425-11 CARBON 4.7K 5% 1/4W F
R228 1-249-427-11 CARBON 6.8K 5% 1/4W F
R229 1-249-427-11 CARBON 6.8K 5% 1/4W F
R230 1-249-427-11 CARBON 6.8K 5% 1/4W F
R231 1-249-427-11 CARBON 6.8K 5% 1/4W F
R232 1-249-411-11 CARBON 330 5% 1/4W
R233 1-249-413-11 CARBON 470 5% 1/4W F
R234 1-249-415-11 CARBON 680 5% 1/4W F
R235 1-249-417-11 CARBON 1K 5% 1/4W F
R236 1-249-419-11 CARBON 1.5K 5% 1/4W F
R237 1-249-421-11 CARBON 2.2K 5% 1/4W F
R238 1-247-843-11 CARBON 3.3K 5% 1/4W
R240 1-249-411-11 CARBON 330 5% 1/4W
R241 1-249-413-11 CARBON 470 5% 1/4W F
R242 1-249-415-11 CARBON 680 5% 1/4W F
R243 1-249-417-11 CARBON 1K 5% 1/4W F
R244 1-249-419-11 CARBON 1.5K 5% 1/4W F
R245 1-249-421-11 CARBON 2.2K 5% 1/4W F
R246 1-247-843-11 CARBON 3.3K 5% 1/4W
R247 1-249-425-11 CARBON 4.7K 5% 1/4W F
R248 1-249-411-11 CARBON 330 5% 1/4W
R249 1-249-413-11 CARBON 470 5% 1/4W F
R250 1-249-415-11 CARBON 680 5% 1/4W F
R251 1-249-417-11 CARBON 1K 5% 1/4W F
R252 1-249-419-11 CARBON 1.5K 5% 1/4W F
R253 1-249-421-11 CARBON 2.2K 5% 1/4W F
R254 1-247-843-11 CARBON 3.3K 5% 1/4W
R255 1-249-425-11 CARBON 4.7K 5% 1/4W F
R256 1-249-411-11 CARBON 330 5% 1/4W
R257 1-249-413-11 CARBON 470 5% 1/4W F
R258 1-249-415-11 CARBON 680 5% 1/4W F
R259 1-249-417-11 CARBON 1K 5% 1/4W F
R260 1-249-419-11 CARBON 1.5K 5% 1/4W F
R261 1-249-421-11 CARBON 2.2K 5% 1/4W F
R262 1-249-429-11 CARBON 10K 5% 1/4W
R263 1-249-429-11 CARBON 10K 5% 1/4W
R265 1-249-429-11 CARBON 10K 5% 1/4W
R266 1-249-429-11 CARBON 10K 5% 1/4W
R267 1-249-429-11 CARBON 10K 5% 1/4W
R268 1-249-429-11 CARBON 10K 5% 1/4W
R269 1-249-437-11 CARBON 47K 5% 1/4W
R270 1-247-807-31 CARBON 100 5% 1/4W
R271 1-247-807-31 CARBON 100 5% 1/4W
R272 1-247-807-31 CARBON 100 5% 1/4W
R273 1-247-807-31 CARBON 100 5% 1/4W
R274 1-247-807-31 CARBON 100 5% 1/4W
R275 1-247-807-31 CARBON 100 5% 1/4W
(AEP,UK)
R276 1-249-429-11 CARBON 10K 5% 1/4W
R277 1-249-429-11 CARBON 10K 5% 1/4W
R278 1-249-429-11 CARBON 10K 5% 1/4W
R279 1-249-429-11 CARBON 10K 5% 1/4W
R284 1-249-429-11 CARBON 10K 5% 1/4W
R285 1-249-429-11 CARBON 10K 5% 1/4W
R286 1-249-429-11 CARBON 10K 5% 1/4W
0R298 1-249-381-11 CARBON 1 5% 1/4W F
0R299 1-249-381-11 CARBON 1 5% 1/4W F
RD101 1-249-439-11 CARBON 68K 5% 1/4W
RD102 1-249-439-11 CARBON 68K 5% 1/4W
RD103 1-249-439-11 CARBON 68K 5% 1/4W
RD104 1-249-439-11 CARBON 68K 5% 1/4W
RD105 1-249-439-11 CARBON 68K 5% 1/4W
RD106 1-249-439-11 CARBON 68K 5% 1/4W
RD107 1-249-439-11 CARBON 68K 5% 1/4W
RD108 1-249-439-11 CARBON 68K 5% 1/4W
RD109 1-249-439-11 CARBON 68K 5% 1/4W
RD110 1-249-439-11 CARBON 68K 5% 1/4W
RD111 1-249-439-11 CARBON 68K 5% 1/4W
RD112 1-249-439-11 CARBON 68K 5% 1/4W
RD113 1-249-439-11 CARBON 68K 5% 1/4W
RD114 1-249-439-11 CARBON 68K 5% 1/4W
RD115 1-249-439-11 CARBON 68K 5% 1/4W
RD116 1-249-439-11 CARBON 68K 5% 1/4W
RD117 1-249-439-11 CARBON 68K 5% 1/4W
RD118 1-249-439-11 CARBON 68K 5% 1/4W
RD119 1-249-439-11 CARBON 68K 5% 1/4W
RD120 1-249-439-11 CARBON 68K 5% 1/4W
RD121 1-249-439-11 CARBON 68K 5% 1/4W
RD122 1-249-439-11 CARBON 68K 5% 1/4W
RD123 1-249-439-11 CARBON 68K 5% 1/4W
RD124 1-249-439-11 CARBON 68K 5% 1/4W
RD125 1-249-439-11 CARBON 68K 5% 1/4W
< VARIABLE RESISTOR >
RV201 1-418-773-11 ENCODER, ROTARY (MASTER VOLUME)
< SWITCH >
S202 1-762-875-21 SWITCH, TACTILE (LEVEL)
S203 1-762-875-21 SWITCH, TACTILE (MODE +)
S204 1-762-875-21 SWITCH, TACTILE (MODE -)
S205 1-762-875-21 SWITCH, TACTILE (MD/TAPE)
S206 1-762-875-21 SWITCH, TACTILE (VIDEO)
S207 1-762-875-21 SWITCH, TACTILE (DVD/MULTI CH)
S208 1-762-875-21 SWITCH, TACTILE (TV/SAT)
S211 1-762-875-21 SWITCH, TACTILE (MENU <)
S212 1-762-875-21 SWITCH, TACTILE (MENU -)
S213 1-762-875-21 SWITCH, TACTILE (TREBLE +)
S214 1-762-875-21 SWITCH, TACTILE (TREBLE -)
S215 1-762-875-21 SWITCH, TACTILE (BASS +)
S216 1-762-875-21 SWITCH, TACTILE (BASS -)
S217 1-762-875-21 SWITCH, TACTILE (TUNER)
S218 1-762-875-21 SWITCH, TACTILE (CD)
DISPLAY
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
