STR-DE375
MODEL IDENTIFICATION
— BACK PANEL —
Parts No.
MODEL PARTS No.
AEP model 4-232-119-0s
UK model 4-232-119-1s
Malaysia,Singapore model 4-232-119-3s
E model 4-232-119-4s
Canadian model 4-232-119-5s
Argentina model 4-232-119-7s
System
Power
requirements
Power
consumption
Dimensions
Mass (Approx.)
Supplied
accessories
Tuner section: PLL
quartz-locked digital
synthesizer system
Preamplifier section:
Low-noise NF type
equalizer
Power amplifier section:
Pure-complementary
SEPP
Canadian model:
120 V AC, 60 Hz
Malaysia, Singapore model
220-230 V AC,
50/60 Hz
Other countries:
120/220/240 V AC,
50/60 Hz
Canadian model:
240 VA
Standby mode: 0.5 W
Malaysia, Singapore model
175 W
Standby mode: 0.5 W
Other countries:
160 W
Standby mode: 0.5 W
430 x 145 x 298 mm
Malaysia, Singapore model
5.5 kg
Canadian and other
countries:
6 kg (13 lb 4 oz)
General
The specification measured
is under
• 230 AC 50 Hz condition
(Malaysia, Singapore model)
Design and specifications are
subject to change without notice.
• FM wire antenna (1)
• AM loop antenna (1)
• Remote commander
(remote) (1)
• Size AA (R6) batteries (2)
* You can change the AM tuning interval
between 9 kHz and 10 kHz. Turn off the
receiver and press ?/1 (power) for more
than 4 seconds until “INITIAL” appears.
1) After tuning in any AM station, turn
off the receiver.
2) Hold down PRESET TUNING +
button and press the ?/1 (power)
button. “9k STEP” appears.
To change to 10k Step, repeat step 1 and 2
until “10k STEP” appears. Note that all
preset stations, index names and sound
field are cleared after you make the
procedure above.
Separation
Frequency
response
Selectivity
+0.5
–2
AM tuner section
45 dB at 1 kHz
30 Hz - 15 kHz dB
60 dB at 400 kHz
Tuning range
Antenna
Intermediate
frequency
Usable sensitivity
S/N
Harmonic
distortion
Selectivity
Malaysia, Singapore model
531 - 1602 kHz (9 kHz
step)
Canadian model:
530 - 1710 kHz (10 kHz
step)*
531 - 1710 kHz (9 kHz
step)*
Other countries models:
530 - 1610 kHz (10 kHz
step)*
531 - 1602 kHz (9 kHz
step)*
Loop antenna
450 kHz
50 dB/m (at 999 kHz)
54 dB (at 50 mV/m)
0.5 % (50 mV/m, 400 Hz)
At 9 kHz: 35 dB
At 10 kHz: 40 dB
