xCENTER XXX.X dB
(Center speaker level)
1)
xSURR L XXX.X dB
(Surround speaker (Left) level)
1)
xSURR R XXX.X dB
(Surround speaker (Right) level)
1)
xSB XXX.X dB
(Surround back speaker level)
1)2)
xSB LEFT XXX.X dB
(Surround back (Left) level)
1)3)
xSB RIGHT XXX.X dB
(Surround back (Right) level)
1)3)
xSW XXX.X dB
(Sub woofer level)
1)
Initial setting: 0 dB
You can adjust from –10 dB to +10 dB in 0.5 dB steps.
1)
The parameters can be adjusted seperately for
MULTI CH IN 1 and 2.
2)
Only when the surround back speaker is set to
“SINGLE” in the SET UP menu (page 19).
3)
Only when the surround back speaker is set to
“DUAL” in the SET UP menu (page 19).
x COMP. XXX
(Dynamic range compressor)
Lets you compress the dynamic range of the sound
track. This may be useful when you want to watch
movies at low volumes late at night.
•OFF
The dynamic range is not compressed.
•STD
The dynamic range is compressed as intended by the
recording engineer.
•MAX
The dynamic range is compressed dramatically.
Tip
Dynamic range compressor lets you compress the
dynamic range of the soundtrack based on the dynamic
range information included in the Dolby Digital signal.
We recommend using the “MAX” setting. This greatly
compresses the dynamic range and lets you view
movies late at night at low volumes. Unlike analog
limiters, the levels are predetermined and provide a
very natural compression.
Note
Dynamic range compression is possible with Dolby
Digital sources only.
xEFFECT XXX (Effect level)
Initial setting: STD
Lets you adjust the “presence” of the surround effect.
Resetting sound fields to the
initial settings
Use the buttons on the receiver for the operation.
1 Press ?/1 to turn off the power.
2 While holding down 2CH, press
?/1.
“SF. INITIALIZE” appears in the display
and all sound fields are reset to the initial
setting.
D.RANGE
