29
Additional Information
Troubleshooting
If you experience any of the following difficulties while
using the player, use this troubleshooting guide to help
you remedy the problem. Should any problem persist,
consult your nearest Sony dealer.
There is no sound.
, Check that the player is connected securely.
, Make sure you operate the amplifier correctly.
, When you use the headphones, adjust the volume
with PHONE LEVEL.
There is no sound from the DIGITAL (CD) OUT
connectors.
, The audio signals of the super audio CD cannot be
output from the DIGITAL (CD) OUT connectors.
The disc does not play.
, There is no disc inside the player.
, Place the disc on the disc tray with the label side
up.
, The disc is placed at an angle. Reload the disc.
, Clean the disc (see page 28).
, Moisture has condensed inside the player. Remove
the disc and leave the player turned on for about
an hour.
, There is an incompatible disc on the tray (see page
11).
The remote does not function.
, Remove any obstacles in the path of the remote
and the player.
, Point the remote at the remote sensor on the
player.
, If the batteries in the remote are weak, replace
with new ones.
, Be sure that the command mode of the remote
(position of the CD 1/2 switch, page 9) mutches
the command mode of the player (page 6).
There is no sound from the SUB WOOFER jack.
, Select the playback mode so that the Sub woofer is
set to “a” (page 21).
, When you play a track that does not contain the
LFE signal, the signal outputs from the SUB
WOOFER jack only when you select “5 – Small +
SW” or “FRT – Large + SW” for the Multi-channel
playback mode (page 22).
Specifications
When a super audio CD is played
Playing frequency range 2 Hz to 100 kHz
Frequency response 2 Hz to 50 kHz (–3 dB)
Dynamic range 103 dB or more
Total harmonic distortion rate
0.0020 % or less
Wow and flutter Value of measurable limit (±0.001 %
W. PEAK) or less
When a CD is played
Frequency response 2 Hz to 20 kHz
Dynamic range 98 dB or more
Total harmonic distortion rate
0.0025 % or less
Wow and flutter Value of measurable limit (±0.001 %
W. PEAK) or less
Output connector
*Output only the audio signals of the CD
General
Laser Semiconductor laser
(SACD: λ = 650 nm)
(CD: λ = 780 nm)
Emission duration: continuous
Laser radiant power: 5.47 uW at 650 nm
*These output is the value measured at a distance of about
200mm from the objective lens surface on the optical pick-up.
Power requirements 120 V AC, 60 Hz
Power consumption 25 W
Dimensions (w/h/d) 430 × 108 × 400 mm
(17 × 4 1/4 × 15 3/4 in.)
incl. projecting parts
Mass (approx.) 5.9 kg (13 lbs 1 oz.)
Supplied accessories
See page 4.
Design and specifications are subject to change without notice.
10 mW
Load impedance
ANALOG OUT
DIGITAL (CD)
OUT OPTICAL*
Phono
jacks
Jack type
2 Vrms
(at 50 kilohms)
Square
optical
output
connector
–18 dBm
Over 10 kilohms
Light emitting
wave length:
660 nm
Output level
( )
PHONES
Stereo
phone jack
32 ohms
