26
GB
3 Hang the IR transmitter via hole on the
bottom of the stand on the screw.
Make sure that the IR transmitter does not
move after installation.
Ti
p
You can store the cords in the troughs in the bottom
of the stand.
Note
• Use screws suitable for the material and strength of
the wall.
• Do not install the IR transmitter to a wall of low
strength.
Sony is not liable for any damage or accident incurred
by incorrect installation (i.e. low strength wall, etc.),
incorrect use of this product, or natural disaster.
When connecting/disconnecting the cord, detach the
IR transmitter from the wall first.
30 mm
(1
3
/
16
inch)
4 mm (
3
/
16
inch)
IR transmitter
Stand
Troughs
Stand
