Chapter 8:
Making recordings
Making an audio or a video
recording
You can make an audio or a video recording
from the built-in tuner, or from an audio or
video source connected to the receiver (such
as a CD player or TV).
1
Keep in mind you can’t make a digital
recording from an analog source or vice-versa,
so make sure the components you are
recording to/from are hooked up in the same
way (see
Connecting up
on page 12 for more on
connections).
Above: VSX-517 (left) and VSX-817 (right)
1 Select the source you want to record.
Use the input select buttons (
INPUT
SELECTOR
).
2 Select the input signal (if necessary).
Press
SIGNAL SELECT
(front panel) to select
the input signal corresponding to the source
component (see page 34 for more on this).
3 Prepare the source you want to record.
Tune to the radio station, load the CD, video,
DVD etc.
4 Prepare the recorder.
Insert a blank tape, MD, video etc. into the
recording device and set the recording levels.
2
Refer to the instructions that came with the
recorder if you are unsure how to do this. Most
video recorders set the audio recording level
automatically—check the component’s
instruction manual if you’re unsure.
5 Start recording, then start playback of
the source component.
Note
1
VSX-817 model only
– If you are recording a video source, you need to use the same type of connection for the source as for
the recorder. For example, you can’t record a component hooked up to composite video jacks with a recorder hooked up to the
component video outputs (see
Connecting other video components
on page 16 for more on video connections).
2 The receiver’s volume, balance, tone (bass, treble, loudness), and surround effects have no effect on the recorded signal.
INPUT SELECTOR
DVD 5.1
AUTO SURR STANDARD
ADV.SURR
STEREO/
F.S.SURR
DVRDVD
CD-R
AMFMCD
RECEIVER
TV
MULTI CONTROL
INPUT
SELECT
STANDARD
ADV.SURR
STEREO/
F.S.SURR
AUTOSURR
DVD/LD
TV/SAT
CD
DVR/VCR
FM AM
RECEIVER
TV CTRL
CD-R/TAPE
F.AUDIO
