TUNER
FM wave range........................................... 87.5 – 108 MHz
AM wave range ...........................................530 – 1700 kHz
Number of presets............................................................40
Antenna
FM....................................................... 300 Ω dipole wire
AM.............................................................. Loop antenna
TAPE DECK
Frequency response
CrO
2
tape (type II) .......................... 60 – 15,000 Hz (5 dB)
Normal tape (type I) ....................... 60 – 15,000 Hz (5 dB)
Signal-to-noise ratio
CrO
2
tape (type II) ..............................................≥ 50 dBA
Normal tape (type I) ...........................................≥ 47 dBA
Wow and flutter ................................................≤ 0.4% DIN
SPEAKERS
System ..................shielded 2-way; double port bass reflex
Impedance ..................................................................... 6 Ω
Woofer....................................................................1 x 5.25"
Tweeter.....................................................................1 x 2.5"
Dimensions (w x h x d) ...................... 240 x 310 x 309 (mm)
Weight .................................................................. 4 kg each
FB219W MAGNETICALLY SHIELDED CENTER
SPEAKERS
Impedance ..................................................................... 6 Ω
Frequency range ...........................................75 – 18,000 Hz
Power handling capacity ............................................. 40 W
Sensitivity ................................................................... 89 dB
Driver .......................................................... 1 x 4" full range
Dimensions (w x h x d) ...................... 264 x 140 x 240 (mm)
Weight ........................................................................ 1.5 kg
SPECIFICATIONS
Specifications
AMPLIFIER
Output power
DPL Mode
Left/Right Channel .............................. 2 x 40 W RMS,
6 Ω, 1 kHz, 10% THD
Center Channel ...................................20 W RMS, 6 Ω
Surround Channel .........................2 x 10 W RMS, 3 Ω
Stereo Mode ............................................ 2 x 40 W FTC
(1)
Signal-to-noise ratio..................................... ≥ 75 dBA (IEC)
Frequency response......................... 40 – 20,000 Hz, ± 3 dB
Input sensitivity
AUX/CDR In ...........................................................450 mV
Output
Speakers (Left/Right) .............................................. ≥ 6 Ω
Center Speaker........................................................ ≥ 6 Ω
Surround Speakers .................................................. ≥ 3 Ω
Headphones..............................................32 Ω – 1000 Ω
Subwoofer Out ........................... 1.5 V ±2dB, > 22,000 Ω
Line Out .................................. 500 mV ±2dB, > 22,000 Ω
Digital Out .............................................IEC 958, 44.1 kHz
Surround Out (wireless) ....................................... 350 mV
(1) (6 Ω, 60 Hz – 12.5 kHz, 10% THD)
CD PLAYER
Number of programmable tracks .....................................40
Frequency response..................................... 40 – 20,000 Hz
Signal-to-noise ratio..............................................≥ 76 dBA
Channel separation ..................................... ≥ 79 dB (1 kHz)
Total harmonic distortion ........................... < 0.02% (1 kHz)
FB219W SURROUND SPEAKERS
Impedance ..................................................................... 3 Ω
Frequency range .........................................100 – 15,000 Hz
Output power.................... 2 x 20 W RMS, 1 kHz, THD 10%
Sensitivity ................................................................... 87 dB
Driver .......................................................... 1 x 4" full range
Dimensions (w x h x d) ...................... 174 x 219 x 220 (mm)
Weight .................................................................. 3 kg each
FB219W TRANSMITTER
System ................................................ Radio frequency (RF)
Modulation ...............................Frequency modulation (FM)
S/N in signal............................................................... 95 dB
Step channel frequency................. 913.750 – 915.250 MHz
Transmission power .............................................. < 10 mW
Working range ................................................... up to 100m
Dimensions (w x h x d) ...................... 130 x 206 x 134 (mm)
Weight ...................................................................... 0.26 kg
GENERAL INFORMATION
Material/finish ....................................... Polystyrene/Metal
AC Power ........................................................ 120 V / 60 Hz
Power Consumption
Active........................................................................ 80 W
Standby .................................................................< 15 W
Dimensions (w x h x d) ...................... 265 x 310 x 363 (mm)
Weight
(without speakers) .........................................
7.2 kg
Subject to modification
