En-43
Advanced Operations
On-screen Setup
With the AV receiver connected to a TV, there are two
ways of changing the settings on-screen: using the Quick
Setup or the Setup Menu (HOME).
■ Quick Setup
The Quick Setup provides quick access to frequently used
settings. You can change settings and view the current
information.
■ Setup menu (HOME)
The Setup menu (HOME) provides a convenient way to
change the AV receiver’s various settings. Settings are
organized into 9 categories.
Explanatory Notes
Setting target
Setting options (default setting underlined)
■ Input
`You can select input sources and view the following
information: the name of input selectors, input
assignments, radio information, and ARC function
setting.
In addition, previews of the video streams coming from
HDMI inputs (HDMI IN 1, 2, 3, 4, 5) are displayed.
*1
“EXTRA1” and “EXTRA2” can only be selected if
they are assigned to HDMI, component, coaxial, or
optical inputs.
Use / to select an input source and view the related
information. Pressing ENTER switches to the selected
input source.
■ Audio (➔ page 44)
`You can change the following settings: “Bass”,
“Treble”, “Subwoofer Level”, “Center Level”,
“Audyssey”, “Dynamic EQ”, “Dynamic Volume”,
“Late Night”, “Music Optimizer”, and “Cinema
Filter”.
■ Video
`You can change the following settings: “Wide Mode”
and “Picture Mode
*2
”.
See also:
• “Picture Adjust” (➔ page 56)
■ Information
*3
`You can view the information of the following items:
“Audio”, “Video” and “Tuner”.
■ Listening Mode
*4
`You can select the listening modes that are grouped in
the following categories: “MOVIE/TV”, “MUSIC”,
“GAME”.
Use / to select the category and / to select the
listening mode. Press ENTER to switch to the
selected listening mode.
The on-screen menus appear only on a TV that is
connected to HDMI OUT. If your TV is connected to
other video outputs, use the AV receiver’s display
when changing settings.
This section describes the procedure for using the
remote controller unless otherwise specified.
Using the Quick Setup
1
Press RECEIVER followed by QSETUP.
The Quick Setup will be superimposed on the TV
screen.
2
Use / and ENTER to make the desired selection.
Press Q SETUP to close the menu.
Press RETURN to return to the previous menu.
Q SETUP
RECEIVER
ENTER
/ / /
RETURN
■ Music Optimizer
`Off
`On
BD/DVD
Input
Audio
Video
Information
Listening Mode
To be continued
