OVERALL SPECIFICATIONS
CHANNEL A IN OR CHANNEL B IN, CHANNEL A SPEAKERS OR CHANNEL B SPEAKERS
Continuous output power into 8 Ω and 4 Ω (both channels driven) >35 W (ref. rated THD, 20 Hz – 20 kHz)
Continuous output power into 8 Ω (Mono, Bridge mode) >70 W (ref. 20 Hz - 20 kHz, <0.02 % THD)
Rated THD (250 mW to rated power, CCIF IMD, DIM 100) <0.03 % (ref. 20 Hz - 20 kHz)
IHF dynamic power - 8 Ω 55 W
4 Ω 85 W
2 Ω 95 W
IHF dynamic power (Bridge mode) - 8 Ω 160 W
4 Ω 180 W
Peak output current >20 A (ref. 1 Ω, 1 ms)
Signal/Noise ratio >95 dB (A-weighted, ref. 1 W)
>110 dB (A-weighted, ref. 35 W)
Damping factor >180 (ref. 8 Ω, 50 Hz and 1 kHz)
Frequency response ±0.3 dB (ref. 20 Hz - 20 kHz)
3Hz - 100 kHz (ref. -3 dB)
Input impedance (R and C) 20 kΩ + 470 pF
Input sensitivity 270 mV (ref. rated power)
Voltage gain 35 dB
Minimum input level for AUTO TRIGGER 50 mV at 1 kHz
Time to power OFF at no signal in AUTO mode <10 minutes
POWER CONSUMPTION
Normal operation 270 W (ref. 230V AC 50 Hz; 120V AC 60 Hz)
Standby power <1 W
Idle power <55 W
DIMENSION AND WEIGHT
Dimensions (W x H x D) 435 x 80 x 285 mm (Net)
435 x 95 x 315 mm (Gross*)
Net weight 7.3 kg
Shipping weight 8.8 kg
* - Gross dimensions include feet, front panel buttons and extended speaker terminals.
Specications are subject to change without notice. For updated documentation and features, please log onto www.NADelectronics.com for the latest
information about C 245BEE.
REFERENCE
SPECIFICATIONS
