Clarion XMD3 CD Player User Manual



English
12
XMD3
Seek tuning
1.
Press the [ BAND ] button and select the desired band (FM or AM).
If “MANU” is lit in the display, press and hold the [ BAND ] button
for 1 second or longer. “MANU” in the display goes off and seek
tuning is now available.
2. Press the [ a ] or [ d ] button to automatically seek a station.
When the [ d ] button is pressed, the station is sought in the
direction of higher frequencies; if the [ a ] button is pressed,
the station is sought in the direction of lower frequencies.
Manual tuning
There are 2 ways available: Quick tuning and step tuning.
When you are in the step tuning mode, the frequency changes one
step at a time. In the quick tuning mode, you can quickly tune the
desired frequency.
1.
Press the [BAND] button and select the desired band (FM or AM).
If “MANU” is not lit in the display, press and hold the [BAND]
button for 1 second or longer. “MANU” is lit in the display and
manual tuning is now available.
2. Tune in a station.
Quick tuning:
Press and hold the [ a ] or [ d ] button for 1 second or longer
to tune in a station.
Step tuning:
Press the [ a ] or [ d ] button to manually tune in a station.
Recalling a preset station
A total of 24 preset positions (6-FM1, 6-FM2, 6-FM3, 6-AM) exist
to store individual radio stations in memory. Pressing the corre-
sponding [ DIRECT ] button recalls the stored radio frequency
automatically.
1.
Press the [ BAND ] button and select the desired band (FM or AM).
2. Press the corresponding [ DIRECT ] button to recall the stored
station.
Press and hold one of the [ DIRECT ] buttons for 2 seconds or
longer to store that station into preset memory.
Manual memory
1. Select the desired station with seek tuning, manual tuning or
preset tuning.
2. Press and hold one of the [ DIRECT ] buttons for 2 seconds or
longer to store the current station into preset memory.
Auto store
Auto store is a function for storing up to 6 stations that are auto-
matically tuned in sequentially. If 6 receivable stations cannot be
received, a previously stored station remains unoverwritten at the
memory position.
1.
Press the [ BAND ] button and select the desired band (FM or AM).
2. Press and hold the [ P/A ] button for 2 seconds or longer. The
stations with good reception are stored automatically to the
preset channels.
If auto store is performed in the FM bands, the stations are stored
in FM3 even if FM1 or FM2 was chosen for storing stations.
Radio Operations
FM reception
For enhanced FM performance the tuner includes signal actuated stereo
control, Enhanced Multi AGC, Impulse noise reduction curcuits and
Multipath noise reduction circuits.
Changing the reception area
This unit is initially set to EUROPE frequency intervals of 9kHz for AM and
100kHz for FM. When using it outside the EUROPE, the frequency recep-
tion range can be switched to the intervals below.
Setting the reception area
Any station preset memories are lost when the reception area is
changed.
1. Press the [ BAND ] button and select the desired radio band
(FM or AM).
Europe standard (initial setting)
2-1. While pressing the [ A-M ] button, press and hold the
number “3” of the [ DIRECT ] buttons for 2 seconds or
longer.
U.S. standard (new setting)
2-1. While pressing the [ A-M ] button, press and hold the
number “1” of the [ DIRECT ] buttons for 2 seconds or
longer.
Other countries (new setting)
2-1. While pressing the [ A-M ] button, press and hold the
number “2” of the [ DIRECT ] buttons for 2 seconds or
longer.
Listening to the radio
1. Press the [ PWR ] button and select the radio mode. The
frequency or PS appears in the display.
PS: Programme service name
2. Press the [ BAND ] button and select the radio band. Each time
the button is pressed, the radio reception band changes in the
following order:
FM1 FM2 FM3 AM FM1...
3. Press the [ a ] or [ d ] button to tune in the desired station.
Mute
Use this function to turn off the sound immediately.
1. Press the [ M ] button.
The sound turns off and “MUTE” appears in the display.
2. Press the [ M ] button again to cancel the mute mode.
Tuning
There are 3 types of tuning mode available, seek tuning, manual
tuning and preset tuning.
Frequency
spacing
Frequency
range
Frequency
spacing
Frequency
range
U.S.
standard
10 kHz
530 to
1,710 kHz
200 kHz
87.9 to
107.9 MHz
Europe
(Initial setting)
9 kHz
531 to
1,602 kHz
Seek:100 kHz
Manual:50kHz
87.5 to
108 MHz
Other
countries
9 kHz
531 to
1,629 kHz
50 kHz
87.0 to
108 MHz
AM
FM
