XMD3
6. OPERATIONS
Basic Operations
Note: Be sure to read this chapter referring to the front diagrams of chapter
“2. CONTROLS” on page 3 (unfold).
Turning on/off the power
1. Press the [ PWR ] button.
2. The illumination and display on the unit light up. The unit
automatically remembers its last operation mode and will
automatically switch to display that mode.
3. Press and hold the [ PWR ] button for 1 second or longer to turn
off the power for the unit.
Note:
• System check
The first time this unit is turned on after the wire connections are
completed, it must check what equipment is connected. When
the power is turned on, “SYSTEM” and “PUSH PWR” appear in
the display alternately, so press the [ PWR ] button. The system
check starts within the unit. When the system check is complete,
the power is turned off, so press the [ PWR ] button again.
Selecting a mode
1. Press the [ PWR ] button to change the operation mode.
2. Each time you press the [ PWR ] button, the operation mode
changes in the following order:
Radio mode ➜ CD mode ➜ CD changer mode ➜ TV tuner ➜
AUX mode ➜ Radio mode...
∗External equipment not connected with CeNET is not displayed.
Adjusting the volume
Press the [ w ] or [ z ] button increases or decreases the
volume.
∗The volume level is from 0 (minimum) to 33 (maximum).
Switching the Display
Press the [ D ] button to select the desired display.
Each time you press the [ D ] button, the display switches in the
following order:
∗ Once selected, the preferred display becomes the display default.
When a function adjustment such as volume is made, the screen
will momentarily switch to that function’s display, then revert back
to the preferred display several seconds after the adjustment.
∗
When you have entered a title in a CD, it appears in the sub display. If
you have not entered a title, “NO TITLE” appears in the title display
instead. For information on how to enter a title, refer to the subsection
“Entering titles” in section “Operations Common to Each Mode ”.
Setting the Z-Enhancer Plus
This unit are provided with 3 types of sound tone effects stored in
memory. Select the one you prefer.
∗The factory default setting is “Z+ OFF”.
Each time you press the [ Z+ ] button, the tone effect changes in
the following order:
“Z+ OFF” ➜ “B-BOOST” ➜ “IMPACT” ➜ “EXCITE” ➜ “CUS-
TOM” ➜ “Z+ OFF” ...
• B-BOOST : bass emphasized
• IMPACT : bass and treble emphasized
• EXCITE : bass and treble emphasized mid de-emphasized
• CUSTOM : user custom
• Z+ OFF : no sound effect
Adjusting the tone
Press the [ A-M ] button and select the item to adjust. Each time you
press the [ A-M ] button, the item changes in the following order:
● When “B-BOOST” is set
“S-VOL 0” ➜ “B-BOOST” ➜ “BAL 0” ➜ “FAD 0” ➜ Last func-
tion mode.
● When “IMPACT” is set
“S-VOL 0” ➜ “IMPACT” ➜ “BAL 0” ➜ “FAD 0” ➜ Last func-
tion mode.
● When “EXCITE” is set
“S-VOL 0” ➜ “EXCITE” ➜ “BAL 0” ➜ “FAD 0” ➜ Last func-
tion mode.
● When “CUSTOM” is set
“S-VOL 0” ➜ “BASS” ➜ “TREBLE” ➜ “BAL 0” ➜ “FAD 0” ➜
Last function mode.
● When “Z+ OFF” is set
“S-VOL 0” ➜ “BAL 0” ➜ “FAD 0” ➜ Last function mode.
∗ If sub-woofer is effective, “S-VOL 0” can be selected.
When this unit is turned on, starting and stopping the engine
of a boat with its volume raised to the maximum level may
harm your hearing.
Be careful about adjusting the volume.
IMPORTANT
Door must be totally closed to prevent water go into the set!
OK NG
CAUTION
Main display
Sub (title) display
Clock display
Main display
