14 DXZ835MP
English
Basic Operations
FM reception
For enhanced FM performance the
®
tuner includes signal actuated stereo control,
Enhanced Multi AGC, Impulse noise reduction
curcuits and Multipath noise reduction circuits.
Changing the reception area
This unit is initially set to USA frequency intervals
of 10kHz for AM and 200kHz for FM. When using it
outside the USA, the frequency reception range
can be switched to the intervals below.
●Setting the reception area
1. Press the [BND] button and select the de-
sired radio band (FM or AM).
2. While pressing the [A-M] button and hold the
number “2” of the [DIRECT] buttons for 2
seconds or longer, the reception area
switches from inside the USA to outside the
USA.
3. While pressing the [A-M] button and hold the
number “1” of the [DIRECT] buttons for 2
seconds or longer, the reception area
switches from outside the USA to inside the
USA.
∗ Any station preset memories are lost when the
reception area is changed.
Listening to the radio
1. Press the [FNC] button and select the radio
mode. The frequency in the display.
2. Press the [BND] button and select the radio
band. Each time the button is pressed, the ra-
dio reception band changes in the following
order:
FM1 ➜ FM2 ➜ FM3 ➜ AM ➜ FM1...
3. Press the [a] or [d] button to tune in the
desired station.
Tuning
There are 3 types of tuning mode available, seek
tuning, manual tuning and preset tuning.
Seek tuning
1. Press the [BND] button and select the de-
sired band (FM or AM).
∗ If “MANU” is lit in the display, press and hold
the [BND] button for 1 second or longer.
“MANU” in the display goes off and seek tun-
ing is now available.
Radio Operations
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the Beat EQ
1. Press the [BEQ] button and select the Beat
EQ mode (1 to 3) to adjust.
2. Press the [A-M] button and select “BASS
BOOST or IMPACT or EXCITE”.
3. Turning the [ROTARY] knob clockwise
adjusts in the + direction; turning it
counterclockwise adjusts in the – direction.
∗ When BASS BOOST is selected, you can
adjust the bass in the range of –3 to 3.
∗ When IMPACT and EXCITE is selected, you
can adjust the bass and treble in the range of –3
to 3.
4. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting MAGNA BASS EXTEND
The MAGNA BASS EXTEND does not adjust
the low sound area like the normal sound
adjustment function, but emphasizes the deep
bass sound area to provide you with a dynamic
sound.
∗ The factory default setting is off.
1. Press and hold the [A-M] button for 1 sec-
ond or longer to turn on the MAGNA BASS
EXTEND effect. “M-B EX” lights in the dis-
play.
2. Press and hold the [A-M] button for 1 second
or longer to turn off the MAGNA BASS EX-
TEND effect. “M-B EX” goes on in the dis-
play.
Adjusting the subwoofer output
volume
∗ The factory default setting is “S-VOL 0”. (Ad-
justment range: –6 to +6)
1. Press the [SW-VOL ] button to select the
subwoofer volume increases or decreases.
2. Press and hold the [SW-VOL ] button, the
subwoofer volume automatically increases or
decreases.
