12 DSH920S
English
How to Make Wirings
1. CeNET Cable
Orient the CeNET cable in the direction
shown in the figure and insert it until it is
locked in position. To remove the CeNET
cable, pull it by lightly grasping the slide cap
A in your fingers.
2. SIRIUS antenna
Connect a SIRIUS antenna (sold separately)
to the SIRIUS antenna terminal.
When removing, extract while keep pressing
the portion B.
Note:
• Be sure to turn the main unit power off when the
SIRIUS antenna cable is connected.
• Do not give a strong shock to the antenna con-
nector.
3. CeNET/STAND ALONE switch
Be sure to check to see if the select switch
located on the back side of the main unit is
set to the “CeNET” position.
Also, set it to the “STAND ALONE” position
when the SIRIUS controller (DSC920S), sold
separately, is used.
3
4
