5. OPERATIONS
Basic Operations
CAUTION
Be sure to lower the volume before switching
off the unit power or the ignition key. The unit
remembers its last volume setting.
Turning on/off the power
1. Press the [SRC] button to turn on the power.
2. Press and hold the [SRC] button for 1 second
or longer to turn off the power for the unit.
Selecting a mode
1. Press the [SRC] button to change the
operation mode.
Radio mode ➜ CD mode ➜ Radio mode...
Adjusting the volume
1. Turning the [ROTARY] knob clockwise
increases the volume; turning it
counterclockwise decreases the volume.
∗ The volume level is from 0 (minimum) to
33 (maximum).
Audio Mode Adjustments
1. Press the [A-M] button to select the
adjustment mode. The mode switches as
follows each time the [A-M] button is pressed:
BASS ➜ TREB ➜ BAL ➜ FAD ➜ Previous
mode
∗ When the Z-Enhancer function is turned
on, BASS (bass) and TRE (treble) cannot
be selected.
2. Turning the [ROTARY] knob to adjust the
selected audio mode.
• BASS (bass): Adjustment range; –7 to +7
• TREB (treble): Adjustment range; –7 to +7
•
BAL (balance): Adjustment range; L13 to R 13
• FAD (fader): Adjustment range; F12 to R12
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
∗ The display returns to the previous mode 7
seconds after the adjustment.
Switching display
1. Press and hold the [BND] button, and then
press the [DISP] button to select the desired
display.
The display switches in the following order:
Main display ➜ Clock (CT) display ➜ Main …
∗ If the display is changed by other button
operation when the clock (CT) is displayed,
the clock display returns automatically after
the operation.
Setting the Z-Enhancer
This unit are provided with 3 types of sound
tone effects stored in memory. Select the one
you prefer.
1. Each time you press the [Z] button, the tone
effect changes in the following order:
“Z-ENHANCER 1” (bass emphasized) ➜
“Z-ENHANCER 2” (treble emphasized) ➜
“Z-ENHANCER 3” (bass and treble
emphasized) ➜ “Z-EHCR OFF” (no sound
effect) ➜ “Z-ENHANCER 1”...
Turning on/off MAGNA BASS
EXTEND
1. Press and hold the [A-M] button for 1 second
or longer to turn the MAGNA BASS EXTEND
and “M-B EX” in the display lights on or off.
CT (Clock Time) function
1. Press and hold the [BND] button, and then
press the [DISP] button, the display switches
to CT (Clock Time) from RDS data.
Triggered audio mute for cellular
telephones
This unit requires special wiring to mute the
audio signal automatically when a cellular
telephone rings in the car.
1. Press and hold the [BND] button, and then
press the [ ] to select the “TEL MUTE” or
“TEL OFF”.
TEL MUTE : mutes the audio sound.
TEL OFF : does not mute the audio sound.
Illumination dimmer function
When the illumination line of this unit is connected
with the car-side illumination signal line, the
display illumination of this unit dims in connection
with turning on the car-side illumination.
Turning the screen saver function
on or off
1. Press the [SS] button while keeping the
[BND] button pressed, to turn the screen
saver function on or off.
