Clarion BD169R CD Player User Manual



280-8304-00
English
DB168R/BD169R/BD169RG 5
4. NOMENCLATURE
Note:
Be sure to read this chapter referring to the front diagrams of chapter 1. CONTROLS on page 2.
Names of the Buttons and their Functions
[RELEASE] button
Press the [RELEASE] button to unlock the
DCP.
[ROTARY] knob
Adjust the volume by turning the knob
clockwise or counterclockwise.
Use the knob to perform various settings.
[CD SLOT]
CD insertion slot.
[PTY] button
Use the button to set the PTY (Programme
Type) standby mode or PTY items.
[Q] button
Ejects a CD when it is loaded into the unit.
[DIRECT] button
Stores a station into memory or recall it
directly while in the radio mode.
[RPT] button
Plays repeatedly while in the CD mode.
[RDM] button
Performs random play while in the CD mode.
[SCN] button
Performs scan play for 10 seconds of each
track while in the CD mode.
[SS] button
Press the [SS] button while keeping the [BND]
button pressed, to turn the screen saver
function on or off.
[ ] button
Plays or pauses a CD while in the CD mode.
[TA] button
Use the button to set the TA (Traffic
Announcement) standby mode.
[DISP] button
Press the [DISP] button while keeping the
[BND] button pressed, to switch the display
indication (Main display, clock display).
[AF] button
Press the button to turn on or off the AF
(Alternative Frequency) function.
When the button is pressed and held,
Regional function can select ON or OFF.
[BND] button
Switches the band, or seek tuning or manual
tuning while in the radio mode.
Plays a first track while in the CD mode.
[SRC] button
Press the button to turn on the power.
Press and hold the button for 1 second or
longer to turn off the power.
Switches the operation mode among the radio
mode, etc.
[A-M] button
Press and hold the button for 1 second or
longer to switch the MAGNA BASS EXTEND
on/off.
Use the button to switch to the audio mode
(bass/treble, balance/fader).
[Z] button
Use the button to select one of the three types
of sound characteristics already stored in
memory. (Z-Enhancer)
[å], [] button
Selects a station while in the radio mode or
selects a track when listening to a CD.
Press and hold the button for 1 second or
longer to switches the fast-forward/fast-
backward.
[P/A] button
Performs preset scan while in the radio mode.
When the button is pressed and held, auto
store is performed.
