6. EXTERNAL CONNECTION AND MEDIA PLAYER
MP3 music files are audio compression format. This unit can play MP3 directly from files contained on a
USB Memory Stick, SD Card.
1. Open the cover marked USB icon on the front panel.
2. Insert the USB device into the USB socket. The unit starts
playing from the USB device automatically.
NOTE
Ensure that the USB device contains playable music.
Remove the USB Device
Insert the Memory Card
Insert the USB Device
Before remove the USB stick from the front panel. Always remember to switch off the unit's power then
remove out the USB Stick.
1. Press panel button to release the front panel.
2. Push the left side of the panel rightward. Pull the panel towards
you to disengage it from the chassis.
3. Insert the card into the card slot in the correct direction until a “
CLICK” sound is heard,
4. Close the front panel, then the unit starts playing from the card
automatically.
Press the unit in off. Press the card until you hear a click sound, the card is now disengaged. then remove
the card.
Remove Memory Card
Connect the external signal to AUX in jack located atthe front of
the panel, then press Mode button to select Aux mode. Press
Mode Button again to cancel Aux Mode and return to previous
mode.
You can reset the unit to its default setting.
The RESET button is located on the main unit (as shown on the diagram). To press it vertically with a
ballpoint pen or metal object will activate it.
The reset button is to be activated for the following reasons:
1. Initial installation of the unit when all wiring is completed.
2. All the function buttons do not operate.
3. Error symbol on the display.
USB DEVICE OPERATION
MEMORY CARD OPERATION
CONNECT THE AUX-IN
RESET THE UNIT
EN - 7
PRESS DOWN
RESET
