60 MX7 Multi-Charger (Optional)
MX7 Reference Guide E-EQ-MX7RG-B
Multi-Charger Indicators
LED Functions
Function LED Indicator Description
No Battery/power Off Battery pack not plugged in or no power
applied.
Charged Green Battery pack fully charged.
Charging Red Battery pack charging.
Standby Yellow Battery pack temperature out of range.
Fault Flashing Red on any
station
Battery pack fault or failure.
Timeout Flashing Red on any
station
Battery analyzer’s four hour timeout period
expired.
Charger/Analyzer
Failure
Flashing Red on all
stations.
Battery analyzer fault or failure.
LCD Messages
LCD Indicator Function Description
ANALYZE
Analyzing the
Battery
Battery pack cycling through Charge, Discharge,
Charge.
CHARGE Charge Battery pack charging.
DISCHARGE Discharge Battery pack discharging.
BAT. FAULT Battery Fault Battery pack fault or failure.
READY
Analysis
Complete
Battery pack analyzed and ready for use with displayed
capacity.
XXXX mAH Display Capacity Capacity measured during discharge cycle.
XX VDC Display volts
Battery volts measured during charge and discharge
cycle.
