A10
Controlling the Multiple Product
RS-232C
RJ-45
RS-232C
RJ-45
Header (5 bytes) Payload (4 bytes)
Checksum
(1byte)
command
Prex code
#0
Prex code
#1
Set
ID
Payload
Type
# of
payload
bytes
Command data #0 data #1 data #2 CS #0
Set
XinemaSound
Leveler
0xCC 0x33 0 4 0x61 0: Off
1: On
reserved (0x00) reserved
(0x00)
Header XOR
Payload
Ack Set
XinemaSound
Leveler
0xCC 0x55 0 4 0x61 0xE0 : OK
0xE1 : NG
reserved (0xFF) reserved
(0xFF)
Header XOR
Payload
Read
XinemaSound
Leveler
0xCC 0x33 1 4 0x61 reserved (0x00) reserved (0x00) reserved
(0x00)
Header XOR
Payload
Ack Read
XinemaSound
Leveler
0xCC 0x55 1 4 0x61 0xE0 : OK
0xE1 : NG"
0: Off
1: On
reserved
(0xFF)
Header XOR
Payload
Set Bass 0xCC 0x33 0 4 0x62 0: -12
…
12 : 0
...
24: 12
reserved (0x00) reserved
(0x00)
Header XOR
Payload
Ack Set Bass 0xCC 0x55 0 4 0x62 0xE0 : OK
0xE1 : NG
reserved (0xFF) reserved
(0xFF)
Header XOR
Payload
Read Bass 0xCC 0x33 1 4 0x62 reserved (0x00) reserved (0x00) reserved
(0x00)
Header XOR
Payload
Ack Read
Bass
0xCC 0x55 1 4 0x62 0xE0 : OK
0xE1 : NG
0: -12
…
12 : 0
...
24: 12
reserved
(0xFF)
Header XOR
Payload
Set Treble 0xCC 0x33 0 4 0x63 0: -12
…
12 : 0
...
24: 12
reserved (0x00) reserved
(0x00)
Header XOR
Payload
Ack Set
Treble
0xCC 0x55 0 4 0x63 0xE0 : OK
0xE1 : NG
reserved (0xFF) reserved
(0xFF)
Header XOR
Payload
Read Treble 0xCC 0x33 1 4 0x63 reserved (0x00) reserved (0x00) reserved
(0x00)
Header XOR
Payload
Ack Read
Treble
0xCC 0x55 1 4 0x63 0xE0 : OK
0xE1 : NG
0: -12
…
12 : 0
...
24: 12
reserved
(0xFF)
Header XOR
Payload
Set Lip Sync 0xCC 0x33 0 4 0x64 0~5 reserved (0x00) reserved
(0x00)
Header XOR
Payload
Ack Set Lip
Sync
0xCC 0x55 0 4 0x64 0xE0 : OK
0xE1 : NG
reserved (0xFF) reserved
(0xFF)
Header XOR
Payload
Read Lip
Sync
0xCC 0x33 1 4 0x64 reserved (0x00) reserved (0x00) reserved
(0x00)
Header XOR
Payload
Ack Read Lip
Sync
0xCC 0x55 1 4 0x64 0xE0 : OK
0xE1 : NG
0~5 reserved
(0xFF)
Header XOR
Payload
Set Speakers 0xCC 0x33 0 4 0x65 0 : Off
1 : On
reserved (0x00) reserved
(0x00)
Header XOR
Payload
Ack Set
Speakers
0xCC 0x55 0 4 0x65 0xE0 : OK
0xE1 : NG
reserved (0xFF) reserved
(0xFF)
Header XOR
Payload
Read
Speakers
0xCC 0x33 1 4 0x65 reserved (0x00) reserved (0x00) reserved
(0x00)
Header XOR
Payload
