A9
Controlling the Multiple Product
RS-232C
RJ-45
Header (5 bytes) Payload (4 bytes)
Checksum
(1byte)
command
Prex code
#0
Prex code
#1
Set
ID
Payload
Type
# of
payload
bytes
Command data #0 data #1 data #2 CS #0
Ack Read
Digital NR
0xCC 0x55 1 4 0x4E 0xE0 : OK
0xE1 : NG
0 : Off
1 : Low
2 : Medium
3 : High
reserved
(0xFF)
Header XOR
Payload
Set Film
Mode
0xCC 0x33 0 4 0x4F 0 : Off
1 : Auto
reserved (0x00) reserved
(0x00)
Header XOR
Payload
Ack Set Film
Mode
0xCC 0x55 0 4 0x4F 0xE0 : OK
0xE1 : NG
reserved (0xFF) reserved
(0xFF)
Header XOR
Payload
Read Film
Mode
0xCC 0x33 1 4 0x4F reserved (0x00) reserved (0x00) reserved
(0x00)
Header XOR
Payload
Ack Read
Film Mode
0xCC 0x55 1 4 0x4F 0xE0 : OK
0xE1 : NG
0 : Off
1 : Auto
reserved
(0xFF)
Header XOR
Payload
Set Balance 0xCC 0x33 0 4 0x56 0 : L50
~
49 : L1
50 : 0
51 : R1
~
100 : R50
reserved (0x00) reserved
(0x00)
Header XOR
Payload
Ack Set
Balance
0xCC 0x55 0 4 0x56 0xE0 : OK
0xE1 : NG
reserved (0xFF) reserved
(0xFF)
Header XOR
Payload
Read Balance 0xCC 0x33 1 4 0x56 reserved (0x00) reserved (0x00) reserved
(0x00)
Header XOR
Payload
Ack Read
Balance
0xCC 0x55 1 4 0x56 0xE0 : OK
0xE1 : NG
0 : L50
~
49 : L1
50 : 0
51 : R1
~
100 : R50
reserved
(0xFF)
Header XOR
Payload
Set Volume 0xCC 0x33 0 4 0x58 0~100 reserved (0x00) reserved
(0x00)
Header XOR
Payload
Ack Set
Volume
0xCC 0x55 0 4 0x58 0xE0 : OK
0xE1 : NG
reserved (0xFF) reserved
(0xFF)
Header XOR
Payload
Read Volume 0xCC 0x33 1 4 0x58 reserved (0x00) reserved (0x00) reserved
(0x00)
Header XOR
Payload
Ack Read
Volume
0xCC 0x55 1 4 0x58 0xE0 : OK
0xE1 : NG
0~100 reserved
(0xFF)
Header XOR
Payload
Set Sound
Reset
0xCC 0x33 0 4 0x59 reserved (0x00) reserved (0x00) reserved
(0x00)
Header XOR
Payload
Ack Set
Sound Reset
0xCC 0x55 0 4 0x59 0xE0 : OK
0xE1 : NG
reserved (0xFF) reserved
(0xFF)
Header XOR
Payload
Set
XinemaSound
3D
0xCC 0x33 0 4 0x60 0: Off
1: On
reserved (0x00) reserved
(0x00)
Header XOR
Payload
Ack Set
XinemaSound
3D
0xCC 0x55 0 4 0x60 0xE0 : OK
0xE1 : NG
reserved (0xFF) reserved
(0xFF)
Header XOR
Payload
Read
XinemaSound
3D
0xCC 0x33 1 4 0x60 reserved (0x00) reserved (0x00) reserved
(0x00)
Header XOR
Payload
Ack Read
XinemaSound
3D
0xCC 0x55 1 4 0x60 0xE0 : OK
0xE1 : NG
0: Off
1: On
reserved
(0xFF)
Header XOR
Payload
