6 Peripheral Administration Modem Administration
UCS 1000 R4.2 Administration 585-313-507 Issue 3 April 2000 265
~ 6 = 2400
~ 7 = 200, V.22
~ 8 =1200, 212A
~ 20 = 19200
For example, to set the 3820 modem to use COM1, where the baud is
19200, enter 20 as the dial line rate as shown below:
AT&TF3L0&D2&S1\N0\Q3S41=20S2=128&W0
Modem response:
OK
7 Disconnect the terminal.
8 Connect the modem to COM port 1.
Note:
COM port 2 (COM2) is reserved for the TAM.
The system activates the RTS, CTS, and LSD indicators.
