page | 49
Appendix
Specications
Supported Formats
Resolutions (max.) 3840 x 2160 (Ultra HD 4K x 2K)
2048 x 1536 (QXGA)
1920 x 1200 (WUXGA)
1080p Full HD
Electrical
Maximum Pixel Clock 300 MHz
EDID Bank Size (each bank) 256 bytes
EDID Write Protect Switch 1 x slide-type
EDID Program Button 1 x tact-type
EDID Programming Switches 3 x DIP-type
HDCP Pass-through / Block Switch 1 x DIP-type
EQ Level Switch 1 x 8-position, rotary-type
Connectors
Video Input 1 x HDMI Type A 19-pin, female, locking
Video Output 1 x HDMI Type A 19-pin, female, locking
USB Mini-B
Operational
Power Input 1 x 5V DC
Power Consumption 1.5W (max.)
Physical
Dimensions (W x H x D) 2.7” x 1.3” x 1.8”
(68mm x 33mm x 46mm)
Unit Weight 0.2 lbs (0.08 kg)
