34 About Your Tablet-PC
Right Side View
WIRELESS RADIO ON/OFF SWITCH — When enabled through Dell QuickSet, this
switch can scan for a wireless local area network (WLAN) in your vicinity. You can also
use it to rapidly turn off or on any wireless devices such as WLAN cards and internal
cards with Bluetooth wireless technology (see "Dell Wi-Fi Catcher™ Network Locator"
on page 109). When moved toward the front of the Tablet-PC, the switch is off; when
moved toward the back of the Tablet-PC, the switch is on.
BACKLIT WI-FI CATCHER™ BUTTON — Scans for WLAN networks (see "Dell Wi-Fi
Catcher™ Network Locator" on page 109). The light operates as follows:
1 wireless radio on/off switch 2 Wi-Fi Catcher™ button
3 USB connector 4 ExpressCard slot
5 Secure Digital (SD) card slot 6 headphones connector
7 microphone connector 8 security cable slot
1 wireless radio on/off switch 2 Wi-Fi Catcher™ button
1 4 5 82 3 76
1 2
