Adding and Replacing Parts 189
Installing the Palm Rest
1
Place the palm rest on top of the base, and engage the snaps around the
palm rest edges by pressing with your fingers in a counter-clockwise
manner.
2
Turn the Tablet-PC upside down and tighten the eleven M2.5 x 5-mm
bottom screws.
3
Turn the Tablet-PC top-side up and tighten the five M2.5 x 5-mm screws
labeled with a "P".
4
Connect the touch pad cable to the system board connector.
5
Install any Mini-Cards (see "Installing a Mini-Card" on page 173).
6
Install the keyboard (see "Installing the Keyboard" on page 177).
7
Install the display assembly (see "Installing the Display Assembly" on
page 182).
8
Install the hinge cover (see "Installing the Hinge Cover" on page 175).
9
Install the hard drive (see "Installing the Hard Drive" on page 161).
System Board
CAUTION: Before performing the following procedures, follow the safety
instructions in your
Product Information Guide
.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching a connector on the back panel of the
Tablet-PC.
NOTICE: To avoid damaging the system board, you must remove the main battery
before you begin working inside the Tablet-PC.
Removing the System Board
1
Follow the procedures in "Before You Begin" on page 155.
2
Remove the hinge cover (see "Removing the Hinge Cover" on page 174).
1 palm rest 2 base
3 touch pad cable-locking arm 4 touch pad cable
