81
GB
Amplifier section
Stereo mode (rated) 65 W+65 W (4 ohms at
1 kHz, DIN)
Surround mode (reference)
Front: 96 W+96 W
(with SS-TS11)
Center: 96 W
(with SS-CT11)
Surround: 96 W+96 W
(with SS-TS11)
Subwoofer: 170 W
(with SS-WS11)
* Depending on the sound field settings and the source,
there may be no sound output.
Inputs VIDEO (AUDIO IN):
Sensitivity: 250 mV
Impedance: 50 kilohms
SAT (AUDIO IN):
Sensitivity: 450 mV
Impedance: 50 kilohms
Phones Accepts low-and high-
impedance headphones.
Super Audio CD/DVD system
Laser Semiconductor laser
(Super Audio CD/DVD:
λ = 650 nm)
(CD: λ = 780 nm)
Emission duration:
continuous
Signal format system PAL/NTSC
Frequency response (at 2 CH STEREO mode)
DVD (PCM): 2 Hz to 22
kHz (±1.0 dB)
CD: 2 Hz to 20 kHz (±1.0
dB)
Tuner section
System PLL quartz-locked digital
synthesizer system
FM tuner section
Tuning range 87.5 – 108.0 MHz (50 kHz
step)
antenna (aerial) FM wire antenna (aerial)
antenna (aerial) terminals 75 ohms, unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
Tuning range 531 – 1,602 kHz (with the
interval set at 9 kHz)
antenna (aerial) AM loop antenna (aerial)
Intermediate frequency 450 Hz
Video section (EURO AV)
Outputs Video: 1 Vp-p 75 ohms
Speakers
Front/Surround
Speaker system Bass reflex
Speaker unit 70 mm dia. cone type
Rated impedance 4 ohms
Dimensions (approx.) 260 × 1,108 × 260 mm
(w/h/d)
Mass (approx.) 3.5 kg
Center
Speaker system Bass reflex
Speaker unit 70 mm dia. cone type
Rated impedance 4 ohms
Dimensions (approx.) 291 × 99 × 79 mm
(w/h/d, with the stand)
Mass (approx.) 0.8 kg
Subwoofer
Speaker system Bass reflex
Speaker unit 160 mm dia. cone type
Rated impedance 2 ohms
Dimensions (approx.) 177 × 380 × 402 mm
(w/h/d)
Mass (approx.) 6.7 kg
Specifications
continued
