12
GB
Connect the supplied speaker system using the supplied speaker cords by matching the colors of the
jacks to those of the cords. For the surround speakers, connect them to the surround amplifier that
receives the sound by wireless. Do not connect any speakers other than those supplied with this system.
To obtain the best possible surround sound, specify the speaker parameters (distance, level, etc.) on
page 29.
Required cords
Speaker cords
The connector and the color tube of the speaker cords are the same color as the label of the jacks to be
connected.
Required equipments for the wireless system
IR transmitter
Transmits the sound by the infrared ray. Connect it to the system.
IR receiver
Receive the sound by the infrared ray. Connect it to the surround amplifier.
Step 1: Speaker System Hookup
(–)
(+)
color tube
(+)
(–)
