Getting Started
7
GB
Plug type B
Plug type C
Note
To prevent noise pickup, keep the antennas away from
the system and other components.
3 For models with a voltage selector, set
VOLTAGE SELECTOR to the local
power line voltage. The voltage
selector is located at the bottom of the
apparatus.
Refer to the print on your system’s
VOLTAGE SELECTOR for available
settings
* Saudi Arabian model: 120 – 127 V
4 Connect the power cord to a wall
outlet.
If the plug does not fit the wall socket,
detach the supplied plug adaptor (only for
models equipped with an adaptor).
To turn on the system, press ?/1.
Inserting two R6 (size AA)
batteries into the remote
Note
If you do not use the remote for a long period of time,
remove the batteries to avoid possible damage from
battery leakage and corrosion.
Tip
When the remote no longer operates the system,
replace both batteries with new ones.
FM
75
COAXIAL
AM
ANTENNA
Extend the FM lead
antenna horizontally
AM loop antenna
FM
75
COAXIAL
AM
ANTENNA
Extend the FM lead
antenna horizontally
AM loop antenna
North American models:
Connect using the white side
Other models:
Connect using the brown side
*
