USING THE HTR 2 REMOTE CONTROL
KEYKEY
KEYKEY
KEY
-ILLUMINA-ILLUMINA
-ILLUMINA-ILLUMINA
-ILLUMINA
TION TIMEOUTTION TIMEOUT
TION TIMEOUTTION TIMEOUT
TION TIMEOUT
The HTR 2’s key-illumination can be set to remain lit for 0-9 seconds. The default value is 2 seconds.
To set the illumination timeout, simultaneously press-and-hold for 3 seconds both the HTR 2’s [DISP] and the
[0-9] key, with the digit corresponding to the desired timeout duration; the Learn LED will flash twice to
confirm the new setting. When set to zero, the illumination will not turn on at all.
NOTE: Key illumination is the biggest drain on the HTR-2’s batteries. A short key-illumination timeout will
extend battery life appreciably; turning it off altogether (set it to 0 seconds) will lengthen it still further.
FACTORY RESETFACTORY RESET
FACTORY RESETFACTORY RESET
FACTORY RESET
The HTR-2 can be reset to its factory state, deleting all learned commands, copied and punched-through
keys, macros, and other setup information, reverting all keys to their pre-programmed library commands. To
perform a factory reset simultaneously press-and-hold for 10 seconds the HTR 2’s [ON] and [RTN] keys; the
Learn LED will start to flash green. Release [ON] and [RTN] before the second flash is complete; the Learn
LED will turn red, indicate the remote has been reset.
NOTE: You must release [ON] and [RTN] before the second flash goes out, otherwise the unit will not
reset; should this occur, repeat the full procedure.
DELETE MODEDELETE MODE
DELETE MODEDELETE MODE
DELETE MODE
The HTR 2 can store learned, copied, and “default library” commands on any single key. (The default library
commands are the pre-programmed NAD codes, such as the native T 744 commands on the [AMP] “page.”)
You can delete commands by layers back “down” to the default library command on any key, removing
learned commands, punched-through functions, and copied keys.
NOTE: The default library commands cannot be deleted, so you need not worry that using Delete Mode
might cause irreparable changes.
To enter Delete Mode, simultaneously press-and-hold for 3 seconds both the desired key’s Device Selector
key and the [RTN] key, until the Learn LED turns green. Press the function key whose command you wish
to delete; the Learn LED flashes; the number of times indicates which type of function has become active—
see the table below. Press the active Device Selector key again to exit Delete Mode.
NOTE: You may delete multiple function-key commands on the same Device Selector “page,” but to
delete from more than one Device Selector page you must exit Delete Mode and then re-enter it on the
required page.
Flashes Command Type
1 Default Library Command
2 Copied Library Command
3 Learned Command
LOADING CODE-LIBRARIESLOADING CODE-LIBRARIES
LOADING CODE-LIBRARIESLOADING CODE-LIBRARIES
LOADING CODE-LIBRARIES
The HTR 2 can store a different library of default NAD codes for each of its Device Selector “pages.” If the
original default library does not control your NAD CD player, tape deck, DVD player, or other component,
follow the procedure below to change the code-library.
Begin by ensuring that the component you wish the HTR 2 to control is plugged in and powered-up (“on,”
not merely in standby). To enter the HTR 2’s Library Mode, simultaneously press-and-hold for 3 seconds both
the desired Device Selector key and the [A/V PRESET] key, until the Learn LED turns green. While keeping
the HTR 2 pointed toward the component, enter the first appropriate three-digit code-library number from
the table below. If the component turns off, press [ENTER] to accept that code-library number and exit the
Library Mode. If the component does not turn off, enter the next three-digit code-library number from the
table. When you enter the correct number the component will turn off; press [ENTER] to accept that code-
library number and exit the Library Mode.
NAD-brand component HTR 2 code-library numbers
CD
CD Player (new) 200
CD Player (old) 201
TAPE
Tape Deck B 400
Tape Deck A 401
DVD
T562 600
T550, L55 601
T512, T531, T532 602
T571, T572 602
L56 604
T513, T533 605
