MPS1611P manual
PN#
7/08/2005 rev. 1.05 No Al pt/qrk
©2005 M&K Sound, Inc. All rights reserved. Product specifications and appearance may change without notice.
15. SPEAKER MOUNTING OPTIONS
The MPS-1611P, like all Miller & Kreisel Professional monitors, has many stand, wall and ceiling mounting options that
make proper placement and installation easy and straightforward. M&K ST series wall brackets and stands (see Figures 3-5),
are recommended because they are designed to facilitate proper installation. For more specific installation instructions, please
consultant the manuals included with the stand and bracket hardware. Information on various bracket and stand options can
be obtained by visiting our web site or referring to our accessory catalog.
M&K Wall Mounting:
Requires M&K ST-Wall Tilt Bracket &
ST-Uni III Bracket
M&K ST-Stand System:
Requires ST-Leg Tilt Kit, ST-1Base, &
ST-Uni III Bracket
FIGURE 4
FIGURE 6
FIGURE 5
M&K ST-Stand System:
Requires ST-Leg Tilt Kit, ST-1Base, &
ST-Uni III Bracket
ST-1 Base (53 lbs)
(order as ST-1 BASE)
2.75" H x 12" W x 13" D
17.5" Leg with Cover
ST Tilt Bracket
(order as ST-TILT BRKT)
25" Leg with Cover
12 UP
5 DOWN
O
O
Universal "L" Bracket
(order as ST-UNI III)
