The presets contain valid parameters under any condition.
This makes Programming and Editing the same function.
The word “Edit” will describe both programing and editing
functions.
The parameters of the 3 presets stored in the active
Favorite bank can be edited while in the Edit mode. This
allows you to hear your changes and compare them
between channel selections before saving. The active
Favorite button and one of the group buttons will flash
while in the edit mode. The effect group button lit or
flashing indicates the Level can be adjusted. Notice there is
also a red rectangle around the effect group name to the
left of the level on the VFD display.
Press any of the Effect Group buttons. They flash
indicating you are in edit mode but no changes are
made, even when the illuminated group button is
pressed. An illuminated or flashing effect Group button
indicates it is selected.
Select any of the 15 effects in a selected group or
bypass it by repeat pressing the group button. The effect
name is indicated on the display. The word “ ” on
the display indicates the effect group is turned off. Each
time you press a flashing group button, the effect in that
group moves up to the next one. You can also hold
down the button to scroll through the effects. If you
pass up the effect you want, continue scrolling until you
reach the effect again. The chart in Fig. C shows how
the effects in the 3 groups are organized.
The selected effect group button is illuminated. Rotate
the Level control to raise or lower the level of the
selected effect group. The effect group levels ( ) are
indicated on the display to the right of the group name.
A red illuminated rectangle around a group name
indicates it can be adjusted using the Level control.
How to edit the Digital Effects:
Selecting different effects
Change the level of an effect group
Editing the Digital Effects
11
Making temporary changes
Saving the temporary changes
Delete temporary changes and use saved Presets
Once you get your effects set up, you may not want to
make permanent changes during a performance.
As long as you stay on the same Favorites bank and
not disrupt the AC power, you can make temporary
changes without saving. This makes it easy to change
settings for different room acoustics.
Press the Save button. All 3 presets in the selected
Favorites bank are saved.
Select a different Favorites Bank without pressing
save. The temporary changes are lost and originals
restored the next time the un-saved Favorite Bank is
selected.
Turn power off then on again. Any changes not saved
before turning off power will be lost.
Method 1
Method 2
DIGITALEFFECTS
DEL
REV
MOD
SAVE
4
1
2
3
GROUP
LEVEL
FAVORITES
PUSH ON
Type Variation Display Name Type Variation Display Name Type Variation Display Name
NotActive BYPASS Not Active BYPASS Not Active BYPASS
Single ShortDelay 50ms 50 ms Chorus LightDepth 1 Chor 1 Hall 1 1s Hal L 1
Single Medium Delay 100ms 100 ms Chorus LightDepth 2 C hor 2 Hall 1 3s HalL2
Single Medium Delay 200ms 200 ms Chorus Hi Depth 1 Chor 3 Hall 1 5s HalL3
Single Medium Delay 250ms 250 ms Chorus HiDepth2 Chor 4 Room .5s ROOM 1
Single Medium Delay 300ms 300 ms Tremolo Slow TREMO 1 Room 1s ROOM 2
Single Medium Delay 350ms 350 ms Tremolo Fast TREMO 2 Room 2s Room 3
Single Medium Delay 400ms 400 ms Chorus Fast2 FST Chor Room 4s ROOM 4
Multi Tap Delay Triplet Triple 1 Leslie Slow Leslie S Room Hi Damp 3s ROOM 5
Multi Tap Delay TripletPan Triple 2 Leslie Fast Leslie F Hall 2 6s HalL4
Multi TapDelay 4/4Time1 4/4 1 Flanger Light1 Flange 1 Hall 2 10s HalL 5
Multi Tap Delay 4/4 Time pan1 4/4 2 Flanger Light 2 Flange 2 LtoR Gate Hi Dens.500ms L-R Gate
Multi TapDelay 4/4Time2 4/4 3 Flanger Deep Stereo Flange 3 Reverse Gate Lo Dens.100ms Rev L ow
Multi TapDelay 4/4TimePan 2 4/4 3 PitchShifter1 Doubler Doubler ReverseGate Hi Dens.300ms Rev High
Regen40% Delay 100ms Regen 1 PitchShifter1 LightDetune L Detune Forward Gate Lo Dens.100ms Fwd Low
Regen40% Delay 200ms Regen 2 PitchShifter 1 Deep Detune D Detune ForwardGate Hi Dens.300ms Fwd High
DELAY MODULATION REVERB
Fig. C
Effect group selections
EXAMPLE
The Reverb Group of Favorites 1 Rhythm channel
preset is being edited.
Rotate to change Reverb Level
Illuminated red
rectangle
Indicates Reverb
Group is being
edited.
Current group
levels
Press REV button to select next
effect in Reverb Group. Hold to
scroll through.
For example,
The current effect for the Reverb
Group is HALL 1.
Looking at chart Fig. C, HALL 1 is
first effect in the group. If you want
to select ROOM 1 (the fourth effect
in the group), you would press REV
button 3 times or hold it to scroll up
to the ROOM 1 effect.
To avoid repeating
steps during an Edit,
press SAVE every
time you achieve
desirable results.
