Classe Audio CDP-10 CD Player User Manual



26
CDP-10 SPECIFICATIONS
Wow and Flutter Below measurement level
Digital output S/PDIF on RCA connector
75 ohms, 0.5 Volt peak to peak output
Frequency response DC to 20 Khz, + 0.1 dB, 20khz 1.4 dB.
Signal to noise -100 dB typical
D/As 2x Burr Brown PCM1738
Dynamic range 16 bit linear
THD+N Better than -90dB @ 1Khz
Channel separation Better than -100 dB @ 1Khz
Offset voltage Better than ± 0.005 VDC
Clock Jitter Less than 2 picoseconds RMS, 20Hz to 40Khz
Laser semiconductor GaAIAs, 0.5 mw, continuous, 790 nm
Sampling rate 352.8 Khz
Disc rotation velocity 200 – 500 rpm (constant linear velocity)
Quantization 16 bits linear
Error correction CIRC principle
Number of channels 2 channels, stereo
POWER REQUIREMENTS
Europe/UK 180 – 260 VAC, 50 Hz, 18 Watts typ.
Canada/USA/Japan 90 – 130 VAC, 60 Hz, 18 Watts typ.
WEIGHT AND DIMENSIONS:
Dimensions (W x D x H):
Gross 25"x 20" x 9" (63.5 cm x 50.8 cm x 22.8 cm)
Net 19" x 16" x 3.75"
(48.2 cm x 40.7 cm x 7 cm)
Weight:
Gross 24.3 lbs. (11 kg)
Net 17.5 lbs. (8.9kg)
Operating temperature 0ºC to + 40ºC
Storage temperature -20ºC to + 60ºC
Operating position Horizontal, up to ±5º inclination in any direction
