XMD3
4. NOMENCLATURE
Note:
• Be sure to read this chapter referring to the front diagrams of chapter “2. CONTROLS” on page 3 (unfold).
Names of the Buttons and their Functions
[ PWR ] button
• Press the button to turn on the power.
Press and hold the button for 1 second or longer to turn off the
power.
• Switches the operation mode among the radio mode, etc.
[SCN] button
• Performs scan play for 10 seconds for each track while in the
CD mode.
[ RPT ] button
• Repeat play while in the CD mode.
[ HOOK ]
• Open the door by push up the hook.
[ RDM ] button
• Performs random play while in the CD mode.
[ DOOR ]
• Door must be totally closed to prevent water go into the unit.
[ P/A ] button
• Performs preset scan while in the radio mode.
When the button is pressed and held, auto store is performed.
[ D ] button
• Switches the display indication(main display, sub display, clock
display).
[ T ] button
• Use the button to input a title in the CD mode.
• Press and hold the button for 1 second or longer to enter the ad-
just mode.
[ Z+ ] button
• Use the button to select one of the 3 types of sound characteris-
tics already stored in memory.
[ ISR ] button
• Recalls ISR radio station in memory.
• Press and hold for 2 seconds or longer: Stores current station
into ISR memory (radio mode only).
[s] button
• Plays or pauses a CD while in the CD mode.
[ DIRECT ] button
• Stores a station into memory or recall it directly while in the ra-
dio mode.
[ BAND ] button
• Switches the band, or seek tuning or manual tuning while in the
radio mode.
• Plays a first track while in the CD mode.
[ A-M ] button
• Press and hold the button for 1 second or longer to switch the
MAGNA BASS EXTEND on or off.
• Use the button to switch to the audio mode (sub woofer, bass/
treble, balance/fader, Z-Enhancer plus adjustment).
[ w ], [ z ] button
• Press the buttons to increases or decreases the volume.
[ a ], [ d ] button
• Selects a station while in the radio mode or selects a track when
listening to a CD. These buttons are also used to make various
settings.
• Press and hold the button for 1 second or longer to switches the
fast-forward/fast-backward.
[ M ] button
• Turns mute on and off.
[ CD SLOT ]
• CD insertion slot.
[ RESET ] button
• Press and hold the button for about 2 seconds when the follow-
ing symptoms occur.
∗ Nothing happens when buttons are pressed.
∗ Display is not accurate.
[Q] button
• Ejects a CD when it is loaded into the unit.
